Part Number
9Y8419
FUSE
Category: — | Fits: 3306
List Price
$20.96
Direct Replacement Parts (Compatible Models)
暂无配套厂替代件记录, Contact us
Stock Status Available (Contact for Inquiry)
Fits Equipment Models (1)

CAT 9Y8419 FUSE fits Caterpillar 3306. Available for order at WSTPARTS.

135-3086-8288
WeChat: 135-3002-9789 / 135-3086-8288
Business days 8:00–18:00
×

Share This Page

Scan the QR code to share this page

Or copy the link below:

CAT 9Y8419 FUSE for 3306 Caterpillar Part - WSTPARTS

The 9Y8419 FUSE is a genuine and high-quality OEM replacement part compatible with Caterpillar 3306 equipment. It is categorized under Electrical System. Every unit is fitment-verified before dispatch. Manual reference: 3306: GENERATORS, group 108-1870, page 1649; 3306: GENERATORS, group 114-5510, page 1650.

9Y8419 FUSE for Caterpillar 3306 — Genuine CAT & Replacement Part

WSTPARTS supplies genuine CAT and OEM-equivalent direct-replacement FUSE (Part # 9Y8419). Designed for CAT 3306 equipment.

Compatible Models

Key Features

  • ✔ 100% compatible with CAT 3306
  • ✔ Meets Caterpillar original quality and performance standards
  • ✔ Genuine CAT lines: New Genuine / Cat Reman / Cat Classic | OEM-equivalent direct replacements
  • ✔ Available for order, contact for lead time

Specifications

Part Number (MPN)9Y8419
Product NameFUSE
BrandCAT
Applicable Models3306
Weight0.05 kg
ConditionNew (Genuine CAT / OEM-equivalent direct replacement)
Warranty12 Months

Where This Part Fits

Every row below is a real listing of 9Y8419 in the Caterpillar parts manual: the machine it is published under, the system it belongs to, the group number and the manual page. Use it to confirm the part against your own parts book before ordering.

Machine System Group No. Manual Page
3306 GENERATORS 108-1870 p.1649
3306 GENERATORS 114-5510 p.1650
3306 GENERATORS 149-6130 p.1651
3306 GENERATORS 155-3820 p.1652
3306 GENERATORS 155-3822 p.1653
3306 GENERATORS 309-1019 p.1663
3306 GENERATORS 100-3979 p.1640
3306 SERVICE EQUIPMENT AND SUPPLIES 122-4249 p.1903

System Notes — GENERATORS

The generators group covers the alternator end of a generator set: stator, rotor, exciter, bearings, coupling disc, terminal box and the voltage regulation hardware. It converts engine rotation into electrical output at a held voltage and frequency. Bearing wear and insulation degradation are the two long-term concerns — a bearing that starts to rumble will eventually seize and take the rotor with it, while moisture and heat slowly break down winding insulation. Parts in this group are replaced when vibration rises, when insulation resistance falls on a megger test, or when output voltage becomes unstable under load.

System Notes — SERVICE EQUIPMENT AND SUPPLIES

This group covers the equipment and consumables used to service the machine rather than to run it: filter wrenches and service tools, drain and fill hardware, grease fittings and couplers, sight gauges, sampling valves, and the small hardware that makes routine maintenance possible without improvising. Items here are replaced when they no longer seal, no longer hold a setting, or when a stripped fitting turns a ten-minute service job into a two-hour one. Keeping the correct part number on hand matters more than the unit price, because a missing grease coupler usually means a missed lube point.

FAQ

Is 9Y8419 the right part for my machine?
Match the part number on your old part, or send us your equipment serial number — WSTPARTS verifies fitment free of charge for CAT 3306.

Genuine CAT vs direct replacement — what is the difference?
Genuine CAT covers three factory lines: New Genuine, Cat Reman (core exchange with core charge) and Cat Classic (brand-new economy line). OEM-equivalent direct replacements are non-CAT parts; grade and warranty are confirmed in the quotation.

Stock, shipping and warranty?
Lead time confirmed on request; we quote the fastest available option. Every order is covered by a warranty per quotation.

📞 Get a Quote: Contact the WSTPARTS parts team | Email: cat@wstparts.com

Frequently Asked Questions
What equipment does 9Y8419 fit?
CAT 9Y8419 FUSE fits 1 Caterpillar equipment model including 3306, verified against Caterpillar parts manuals and confirmed orders.
Where is 9Y8419 listed in the Caterpillar parts manual?
9Y8419 is listed in the Caterpillar parts manual under 3306, GENERATORS, group 108-1870, page 1649.
How can I order 9Y8419?
Add 9Y8419 to the inquiry cart, or send us your machine model and serial number — we verify the part number before dispatch.

Parts Diagram

100%
3306 · GENERATORS · 108-1870 CAT parts diagram
Scroll to zoom · Drag to pan
Sel 0
18M-8468SEAL-O-RING
26V-8374SCREW-MACHINE (6-32X0.25-IN)
39Y-8420COVER (FUSE)
46V-8185NUT (1/4-20-THD)
54B-4674WASHER (6.4X14.5X1.6-MM THK)
67C-3887BOLT (1/4-20X4.5-IN)
79Y-8419FUSE (12-AMPERE)
84B-1242SCREW-MACHINE (12-24X0.375-IN)
94P-9826BLOCK-FUSE
