| Part No. | Name | Qty | Page |
|---|---|---|---|
| 173-7985 |
173-7985
|
1 | 831 |
| 158-8159 |
HOUSING
|
1 | 832 |
| 153-5242 |
VALVE GP
|
1 | 832 |
| 6E-2274 |
COVER
|
1 | 832 |
| 4J-8998 |
SEAL - O - RING (ID=36.09mm)
|
2 | 832 |
| 1P-3702 |
SEAL
|
2 | 832 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
2 | 832 |
| 8T-4121 |
WASHER
|
4 | 832 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 832 |
| 7X-2545 |
BOLT (L=150mm)
|
8 | 832 |
| 6E-5731 |
VALVE
|
1 | 832 |
| 4K-1388 |
SEAL - O - RING (ID=26.59mm)
|
1 | 832 |
| 6E-5730 |
PLUG
|
1 | 832 |
| 7I-1248 |
SPRING
|
1 | 832 |
| 185-0490 |
VALVE GP
|
2 | 832 |
| 4J-5267 |
SEAL - O - RING (ID=24.99mm)
|
2 | 832 |
| 4B-4158 |
SCREW
|
2 | 832 |
| 173-7985 |
173-7985
|
1 | 726 |
| 153-5242 |
153-5242
|
1 | 726 |
| 185-0490 |
185-0490
|
1 | 726 |
| 158-8159 |
HOUSING
|
1 | 727 |
| 153-5242 |
VALVE GP
|
1 | 727 |
| 6E-2274 |
COVER
|
1 | 727 |
| 4J-8998 |
SEAL - O - RING (ID=36.09mm)
|
2 | 727 |
| 1P-3702 |
SEAL
|
2 | 727 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
2 | 727 |
| 8T-4121 |
WASHER
|
4 | 727 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 727 |
| 7X-2545 |
BOLT (L=150mm)
|
8 | 727 |
| 6E-5731 |
VALVE
|
1 | 727 |
| 4K-1388 |
SEAL - O - RING (ID=26.59mm)
|
1 | 727 |
| 6E-5730 |
PLUG
|
1 | 727 |
| 7I-1248 |
SPRING
|
1 | 727 |
| 185-0490 |
VALVE GP
|
2 | 727 |
| 4J-5267 |
SEAL - O - RING (ID=24.99mm)
|
2 | 727 |
| 4B-4158 |
SCREW
|
2 | 727 |
| 173-7985 |
173-7985
|
1 | 540 |
| 153-5242 |
153-5242
|
1 | 540 |
| 185-0490 |
185-0490
|
1 | 540 |
| 158-8159 |
HOUSING
|
1 | 541 |
| 153-5242 |
VALVE GP
|
1 | 541 |
| 6E-2274 |
COVER
|
1 | 541 |
| 4J-8998 |
SEAL - O - RING (ID=36.09mm)
|
2 | 541 |
| 1P-3702 |
SEAL
|
2 | 541 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
2 | 541 |
| 8T-4121 |
WASHER
|
4 | 541 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 541 |
| 7X-2545 |
BOLT (L=150mm)
|
8 | 541 |
| 6E-5731 |
VALVE
|
1 | 541 |
| 4K-1388 |
SEAL - O - RING (ID=26.59mm)
|
1 | 541 |
