| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 155-2274 |
(INCLUDES PLUG AS, WEDGE, & INTERFACE SEAL) END-WIRE (14-GA)
|
1 | 273 |
| 112-7497 |
112-7497
|
1 | 273 |
| 125-7876 |
TUBE-HEAT SHRINK (17.78-MM DIA) (5-CM)
|
1 | 273 |
| 9X-3402 |
SOCKET-CONNECTOR (16-GA TO 18-GA) –OR–
|
6 | 273 |
| 126-1768 |
SOCKET-CONNECTOR (14-GA TO 16-GA)
|
6 | 273 |
| 162-4171 |
TERMINAL AS (18-GA TO 20-GA) (EACH INCLUDES)
|
6 | 273 |
| 125-7875 |
TUBE-HEAT SHRINK (7.44-MM DIA) (4-CM) TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW)
|
1 | 273 |
| 5P-2321 |
5P-2321
|
9 | 273 |
| 9X-3401 |
PIN-CONNECTOR (16-GA TO 18-GA) –OR–
|
8 | 273 |
| 126-1767 |
PIN-CONNECTOR (14-GA TO 16-GA)
|
8 | 273 |
| 9X-3401 |
PIN-CONNECTOR (16-GA TO 18-GA) –OR–
|
3 | 291 |
| 126-1767 |
PIN-CONNECTOR (14-GA TO 16-GA)
|
3 | 291 |
| 155-2265 |
KIT-CONNECTING PLUG (8-PIN) (INCLUDES PLUG AS, WEDGE & INTERFACE SEAL) KIT-RECEPTACLE (3-PIN)
|
1 | 291 |
| 102-8803 |
(INCLUDES RECEPTACLE AS & WEDGE)
|
1 | 291 |
| 126-1766 |
SOCKET-CONNECTOR (14-GA TO 18-GA)
|
8 | 291 |
| 3S-2093 |
STRAP-CABLE
|
7 | 291 |
| 5P-2321 |
TERMINAL-FORK (14-GA TO 16-GA, NO. 6 SCREW)
|
3 | 291 |
| 125-7875 |
TUBE-HEAT SHRINK (7.44-MM DIA) (10-CM)
|
1 | 291 |
| 6K-0806 |
STRAP-CABLE
|
3 | 373 |
| 154-3488 |
TRANSFORMER AS
|
2 | 373 |
| 125-7874 |
TUBE-HEAT SHRINK (5.72-MM DIA) (18-CM)
|
1 | 373 |
| 9X-3401 |
PIN-CONNECTOR (16-GA TO 18-GA) –OR– PIN-CONNECTOR (14-GA TO 16-GA)
|
8 | 373 |
| 126-1767 |
126-1767
|
8 | 373 |
| 154-3488 |
TRANSFORMER AS
|
2 | 382 |
| 309-1583 |
CONTROL AS-GOVERNOR (LOAD SHARE)
|
1 | 382 |
| 361-1644 |
HARNESS AS-CONTROL
|
1 | 382 |
| 361-1645 |
HARNESS AS-WIRING
|
1 | 382 |
| 368-8600 |
WIRING GP-GENERATOR (POTENTIAL TRANSFORMER)
|
1 | 382 |
| 118-6503 |
BOLT (M6X1X55-MM) WASHER (5.5X13X1.2-MM THK)
|
2 | 382 |
| 4B-4274 |
4B-4274
|
4 | 382 |
| 6V-2687 |
SCREW-PAN HEAD (10-24X1-IN)
|
4 | 382 |
| 9X-8256 |
WASHER (6.6X12X2-MM THK)
|
2 | 382 |
