| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 162-6356 |
GUARD AS
导向护板组件 |
2 | 87 |
| 247-8978 |
MOTOR GP
马达总成 |
1 | 87 |
| 7X-2552 |
BOLT (L=30mm)
螺栓 |
6 | 87 |
| 7X-0515 |
WASHER
卡箍板 |
22 | 87 |
| 139-8878 |
SPIDER AS
|
1 | 87 |
| 210-8048 |
SUPPORT AS
支承组件 |
1 | 87 |
| 162-6354 |
SUPPORT AS
支承组件 |
1 | 87 |
| 210-8047 |
SUPPORT AS
支承组件 |
1 | 87 |
| 8T-4137 |
BOLT (L=20mm)
螺栓 |
6 | 87 |
| 7X-7729 |
WASHER
卡箍板 |
20 | 87 |
| 8T-4139 |
BOLT (L=30mm)
螺栓 |
3 | 87 |
| 139-8733 |
ADAPTER
接头 |
1 | 87 |
| 8T-4223 |
WASHER
卡箍板 |
2 | 87 |
| 8T-4194 |
BOLT (L=50mm)
螺栓 |
2 | 87 |
| 8T-4196 |
BOLT (L=35mm)
螺栓 |
8 | 87 |
| 8T-4121 |
WASHER
卡箍板 |
8 | 87 |
| 139-8753 |
LOCKWASHER
锁紧垫圈 |
1 | 87 |
| 8T-4175 |
BOLT (L=90mm)
螺栓 |
8 | 87 |
| 5P-1076 |
WASHER
卡箍板 |
6 | 87 |
| 8T-4133 |
NUT
螺母 |
2 | 87 |
| 8T-4183 |
BOLT (L=40mm)
螺栓 |
6 | 87 |
| 136-4182 |
BOLT (L=100mm)
螺栓 |
2 | 87 |
| 8T-4132 |
NUT
螺母 |
6 | 87 |
| 147-7049 |
SUPPORT AS
支承组件 |
1 | 87 |
| 151-6533 |
SUPPORT AS
支承组件 |
1 | 87 |
| 8T-4195 |
BOLT (L=30mm)
螺栓 |
10 | 87 |
| 8T-4140 |
BOLT (L=60mm)
螺栓 |
4 | 87 |
| 8T-4186 |
BOLT (L=40mm)
螺栓 |
2 | 87 |
| 162-6357 |
PLATE
凸轮斜盘 |
2 | 87 |
| 4M-0189 |
SEAL-O-RING
O 形密封圈 |
1 | 87 |
