CAT G3616 255-0031 Parts Manual Diagram - CYLINDER HEAD GP –OR–

Home › Parts Manual › CAT G3616 › 255-0031

Part No.

255-0031

Name (EN)

CYLINDER HEAD GP –OR–

Name (CN)

Qty

1 per assembly

Group

114-4301

System

BASIC ENGINE

Source

CAT Official Parts Manual

※ Click image to zoom · Page 93 of official CAT G3616 parts manual

Part No.	Name	Qty	Page
1W-2361	NUT-CYLINDER HEAD (1-5/8-12UN SPL-THD)	4	90
1W-2362	WASHER (41.5X85X12-MM THK)	4	90
2N-3350	SEAL-O-RING	8	90
6V-4314	SEAL-O-RING	2	90
7C-4299	ADAPTER	4	90
8C-5230	SEAL-O-RING	8	90
8C-9023	SEAL-O-RING	2	90
114-4301	PLATE-SEAL	1	90
114-4302	PLATE-SEAL	1	90
143-2878	GASKET	1	90
171-3994	CYLINDER HEAD GP –OR–	1	90
171-3995	CYLINDER HEAD GP –OR–	1	90
194-3250	CYLINDER HEAD GP	1	90
1W-2361	NUT-CYLINDER HEAD (1-5/8-12UN SPL-THD)	4	91
1W-2362	WASHER (41.5X85X12-MM THK)	4	91
2N-3350	SEAL-O-RING	8	91
6V-4314	SEAL-O-RING	2	91
7C-4299	ADAPTER	4	91
8C-5230	SEAL-O-RING	8	91
8C-9023	SEAL-O-RING	2	91
114-4301	PLATE-SEAL	1	91
114-4302	PLATE-SEAL	1	91
143-2878	GASKET	1	91
213-6962	CYLINDER HEAD GP –OR–	1	91
213-6964	CYLINDER HEAD GP	1	91
1W-2361	NUT-CYLINDER HEAD (1-5/8-12UN SPL-THD)	4	92
1W-2362	WASHER (41.5X85X12-MM THK)	4	92
2N-3350	SEAL-O-RING	8	92
6V-4314	SEAL-O-RING	2	92
7C-4299	ADAPTER	4	92
8C-5230	SEAL-O-RING	8	92
8C-9023	SEAL-O-RING	2	92
114-4301	PLATE-SEAL	1	92
114-4302	PLATE-SEAL	1	92
143-2878	GASKET	1	92
219-2955	CYLINDER HEAD GP –OR–	1	92
219-2956	CYLINDER HEAD GP	1	92
1W-2361	NUT-CYLINDER HEAD (1-5/8-12UN SPL-THD)	4	93
1W-2362	WASHER (41.5X85X12-MM THK)	4	93
2N-3350	SEAL-O-RING	8	93
6V-4314	SEAL-O-RING	2	93
7C-4299	ADAPTER	4	93
8C-5230	SEAL-O-RING	8	93
8C-9023	SEAL-O-RING	2	93
114-4301	PLATE-SEAL	1	93
114-4302	PLATE-SEAL	1	93
143-2878	GASKET	1	93
219-2956	CYLINDER HEAD GP	1	93
