| Part No. | Name | Qty | Page |
|---|---|---|---|
| 4B-4281 |
WASHER (2.5MM THK)
|
1 | 594 |
| 3E-7886 |
SENSOR AS-SPEED (TACHOMETER)
|
1 | 594 |
| 7W-3355 |
MAGNETIC PICKUP GP
|
1 | 854 |
| 3S-2093 |
STRAP-CABLE (1.75IN DIA)
|
6 | 854 |
| 9X-1117 |
TACHOMETER
|
1 | 855 |
| 0S-1594 |
BOLT (3/8-16X1IN)
|
16 | 856 |
| 2N-3385 |
NUT-CLIP
|
16 | 856 |
| 3B-4506 |
LOCKWASHER
|
16 | 856 |
| 3L-9689 |
WASHER
|
16 | 856 |
| 1V-0623 |
PLATE
|
8 | 856 |
| 3N-5708 |
GUARD AS-EXTENSION
|
1 | 856 |
| 4P-9063 |
GUARD AS-EXTENSION
|
1 | 857 |
| 1V-0623 |
PLATE
|
4 | 857 |
| 2N-3385 |
NUT-CLIP
|
8 | 857 |
| 4V-8198 |
SPACER
|
8 | 857 |
| 9X-8872 |
BOLT-LOCKING (3/8-16X0.875IN)
|
8 | 857 |
| 9Y-0847 |
SUPPORT-ENGINE (LH)
|
1 | 858 |
| 9Y-0846 |
SUPPORT-ENGINE (RH)
|
1 | 858 |
| 1A-0458 |
BOLT (3/4-10X1.75IN)
|
28 | 858 |
| 5P-8248 |
WASHER-HARD (3.5MM THK)
|
28 | 858 |
| 0S-1587 |
BOLT (1/2-13X1.75IN)
|
16 | 859 |
| 5P-8245 |
WASHER (3MM THK)
|
16 | 859 |
| 8N-7152 |
COUPLING GP-GENERATOR
|
1 | 859 |
| 5N-4479 |
SHIM
|
3 | 859 |
| 1D-4637 |
BOLT (1-8X3.25IN)
|
2 | 859 |
| 5P-8250 |
WASHER (5.0MM THK)
|
4 | 859 |
| 2J-3507 |
NUT-FULL (1-8 THD)
|
4 | 859 |
| 1H-1179 |
SHIM (0.0299IN THK)
|
36 | 859 |
| 9F-8369 |
SHIM
|
18 | 859 |
| 1D-4637 |
BOLT (1-8X3.25IN)
|
4 | 859 |
| 5P-8250 |
WASHER (5.0MM THK)
|
8 | 859 |
