| Part No. | Name | Qty | Page |
|---|---|---|---|
| 036-9823 |
BOLT
|
13 | 639 |
| 3L-3380 |
BUSHING-TERMINAL
|
1 | 639 |
| 3T-3418 |
FRAME AS-END
|
1 | 639 |
| 3T-3423 |
CUP
|
1 | 639 |
| 9G-4101 |
BUSHING-END
|
1 | 639 |
| 3T-3424 |
PLUG-FELT
|
1 | 639 |
| 7M-0327 |
WASHER-THRUST
|
1 | 639 |
| 7M-8651 |
ARMATURE AS
|
1 | 639 |
| 7M-0324 |
COIL AS-FIELD
|
1 | 639 |
| 9H-3757 |
WASHER (3/32IN THK)
|
2 | 639 |
| 7F-3494 |
WASHER-STUD
|
2 | 639 |
| 3H-3681 |
NUT-FULL (1/2-13 THD)
|
2 | 639 |
| 7M-0326 |
CONNECTOR
|
1 | 639 |
| 9B-0453 |
LOCKWASHER
|
2 | 639 |
| 7T-8854 |
SOLENOID AS-STARTING MOTOR
|
1 | 639 |
| 6H-3622 |
SCREW-MACHINE
|
4 | 639 |
| 4M-1831 |
PLUG-LEVER HOUSING
|
4 | 639 |
| 7L-2894 |
GASKET
|
4 | 639 |
| 3F-0379 |
SCREW-POLE SHOE
|
12 | 639 |
| 7M-0325 |
INSULATOR-COIL
|
1 | 639 |
| 7F-3488 |
SHOE-POLE
|
6 | 639 |
| 3T-3106 |
SCREW AS
|
3 | 639 |
| 3T-9524 |
BRUSH AS
|
6 | 639 |
| 2F-2860 |
SCREW-MACHINE
|
6 | 639 |
| 3T-9525 |
PLATE AS-BRUSH
|
1 | 639 |
| 6T-0371 |
INSULATOR
|
1 | 639 |
| 5P-6298 |
SCREW-MACHINE (10-32X0.5IN)
|
12 | 639 |
| 9F-5599 |
LOCKWASHER
|
12 | 639 |
| 6T-0372 |
PLATE
|
1 | 639 |
| 6T-0363 |
HOLDER AS-BRUSH (EACH INCLUDES)
|
6 | 639 |
| 3T-9494 |
SPRING-BRUSH
|
1 | 639 |
| 2L-6679 |
PLATE-INSULATOR
|
3 | 639 |
| 3T-4710 |
PLATE
|
3 | 639 |
| 3T-4709 |
PLATE
|
3 | 639 |
| 7F-3525 |
WASHER-BUSHING
|
6 | 639 |
| 2D-6392 |
SEAL-O-RING (6.07MM ID)
|
1 | 639 |
| 2J-8163 |
SEAL-O-RING (117.07MM ID)
|
2 | 639 |
| 7F-3491 |
WASHER (3/32IN THK)
|
2 | 639 |
| 3H-3680 |
NUT-JAM (1/2-13 THD)
|
2 | 639 |
| 6N-3279 |
INSULATOR
|
1 | 639 |
| 1H-2629 |
STRIP-INSULATION
|
3 | 639 |
| 3T-3422 |
WIRE AS
|
1 | 639 |
| 9M-7606 |
PLUNGER AS
|
1 | 639 |
| 036-9821 |
WASHER
|
1 | 639 |
| 4M-1829 |
BOOT-RUBBER
|
1 | 639 |
| 4M-1828 |
RETAINER-SPRING
|
1 | 639 |
| 9M-7609 |
SPRING
|
1 | 639 |
| 1H-1023 |
SEAL-O-RING (9.25MM ID)
|
1 | 639 |
| 3T-3420 |
HOUSING AS-LEVER
|
1 | 639 |
| 1M-9968 |
BUSHING
|
1 | 639 |
