| Part No. | Name | Qty | Page |
|---|---|---|---|
| 4B-2043 |
NUT (8-32-THD)
|
2 | 340 |
| 9B-7233 |
LOCKWASHER
|
2 | 340 |
| 3N-3469 |
TAG-INSTRUCTION (ENGINE PRESTART) INSTALL ON RH OR LH SIDE ENGINE IN A VISIBLE LOCATION. DO NOT INSTALL ON FRONT OR REAR OF ENGINE OR COMPONENT.
|
1 | 341 |
| 4P-6379 |
FILM-IDENTIFICATION (FUEL FILTER) INSTALL ON SPIN-ON FUEL FILTER. GOSSELIES: INSTALLER SUR LA CARTOUCHE DU FILTRE A FUEL
|
1 | 341 |
| 4W-1413 |
PLATE-SERIAL NUMBER (ENGINE) CONTACT YOUR LOCAL DEALER **REFLATTEN AFTER STAMPING. INSTALL WITH LOCTITE COMPANY DEPEND ADHESIVE ON LH SIDE OF CYLINDER BLOCK TOWARD THE TOP AND REAR FLAT AREA THAT WOULD BE ABOVE AND BEHIND THE ECM WHEN MOUNTED.
|
1 | 341 |
| 7C-8511 |
PLATE-SERIAL NUMBER (ENGINE) CONTACT YOUR LOCAL DEALER ** REFLATTEN AFTER STAMPING. INSTALL WITH LOCTITE COMPANY DEPEND ADHESIVE ON LH SIDE OF CYLINDER BLOCK TOWARD THE TOP AND REAR FLAT AREA THAT WOULD BE ABOVE AND BEHIND THE ECM WHEN MOUNTED.
|
1 | 341 |
| 7E-8050 |
FILM GP (EPA CERTIFICATION) CONTACT YOUR LOCAL DEALER INSTALL ON CENTER OF VALVE COVER WITH TEXT READABLE FROM LH SIDE OF ENGINE AFFIX NEXT TO IMO LABEL. THIS LABEL WILL BE CLOSEST TO THE REAR OF THE ENGINE. INTALL LAMINATE 178-0478 OVER FILM.
|
1 | 341 |
| 7E-8070 |
FILM (INFO) (ENGINE SERIAL NUMBER) CONTACT YOUR LOCAL DEALER INSTALL ON LH SIDE TOWARDS REAR OF ENGINE BELOW VALVE COVER ON VALVE COVER BASE.
|
1 | 341 |
| 8C-8902 |
FILM-IDENTIFICATION (ENGINE OIL FILTER) INSTALL ON SPIN-ON OIL FILTER.
|
1 | 341 |
| 8L-8413 |
STRAP-CABLE INSTALL PRESTART TAG.
|
1 | 341 |
| 115-5852 |
PLATE & FILM GP (ENGINE INFORMATION) CONTACT YOUR LOCAL DEALER INSTALL CENTERED ON VALVE COVER VIEWED FROM LEFT SIDE THIS LABEL WILL BE TO THE LEFT OF THE IMO LABEL AND TO THE RIGHT OF THE OIL FILL. PUT EXTRA LABEL IN PLASTIC BAG ATTACHED TO ENGINE. INSTA
|
2 | 341 |
| 136-9066 |
FILM-ENGINE OIL INSTALL ON TOP OF VALVE COVER ON LEFT REAR ANGLED FLAT SURFACE. NEAR OIL FILL CAP.
|
1 | 341 |
| 178-0480 |
FILM GP (CERTIFICATION) CONTACT YOUR LOCAL DEALER INSTALL ON TOP OF VALVE COVER READABLE FROM LH SIDE OF ENGINE. THIS WILL BE INSTALLED BETWEEN THE ENGINE INFO AND EPA LABEL. INSTALL LAMINATE OVER SILVER FILM.
|
1 | 341 |
