| Part No. | Name | Qty | Page |
|---|---|---|---|
| 100-6772 |
BOLT-HIGH TEMPERATURE (M8X1.25-THD)
|
12 | 117 |
| 130-0073 |
HOUSING-BEARING
|
1 | 117 |
| 8T-1160 |
BOLT-SOCKET HEAD (M10X1.5X50-MM)
|
6 | 117 |
| 4W-8573 |
PLATE-LOCK
|
12 | 117 |
| 4P-0372 |
CONE-AIR
|
1 | 117 |
| 8T-1159 |
BOLT-SOCKET HEAD (M10X1.5X25-MM)
|
3 | 117 |
| 3B-4507 |
LOCKWASHER
|
9 | 117 |
| 4W-7961 |
COVER AS
|
1 | 117 |
| 4W-9032 |
SEAL-O-RING
|
1 | 117 |
| 4P-0307 |
DISC-COVER
|
1 | 117 |
| 7C-3348 |
BEARING-THRUST
|
1 | 117 |
| 8C-8581 |
BOLT-HIGH TEMPERATURE (M10X1.5X30-MM)
|
3 | 117 |
| 4W-8572 |
PLATE-LOCK (1-MM THK)
|
3 | 117 |
| 4W-9033 |
SEAL-O-RING
|
1 | 117 |
| 4W-8683 |
COVER AS
|
1 | 117 |
| 4W-9031 |
SEAL-O-RING
|
1 | 117 |
| 4W-9293 |
BEARING AS (TURBINE)
|
1 | 117 |
| 4W-8927 |
BUSHING-TERMINAL
|
1 | 117 |
| 8T-0267 |
BOLT-SOCKET HEAD (M6X1X12-MM)
|
3 | 117 |
| 4W-8561 |
BEARING AS-COMPRESSOR
|
1 | 117 |
| 4W-8928 |
BUSHING-TERMINAL
|
1 | 117 |
| 8T-0267 |
BOLT-SOCKET HEAD (M6X1X12-MM)
|
4 | 117 |
| 3B-4504 |
LOCKWASHER
|
4 | 117 |
| 4P-0300 |
FLANGE-GAS INLET
|
1 | 125 |
| 7E-9688 |
CLAMP-SEGMENT
|
2 | 125 |
| 7E-9689 |
KEY
|
4 | 125 |
| 7E-9690 |
PIN-SPRING
|
1 | 125 |
| 9X-8275 |
BOLT-SOCKET HEAD (M6X1X10-MM)
|
4 | 125 |
| 100-6777 |
BOLT-HIGH TEMPERATURE (M10X1.5X25-MM)
|
24 | 125 |
| 7E-9699 |
RETAINER-BOLT
|
12 | 125 |
| 4W-7390 |
FLANGE
|
1 | 126 |
| 4W-7391 |
GASKET
|
1 | 126 |
| 4W-7392 |
PIPE
|
1 | 126 |
| 4W-7393 |
ELBOW
|
1 | 126 |
| 4W-7394 |
GASKET
|
2 | 126 |
| 0S-1587 |
BOLT (1/2-13X1.75-IN)
|
6 | 126 |
| 5P-8245 |
WASHER-HARD (13.5X25.5X3-MM THK)
|
6 | 126 |
| 6V-5095 |
SEAL-O-RING
|
4 | 126 |
| 0S-1591 |
BOLT (3/8-16X1.5-IN)
|
16 | 126 |
| 3V-3308 |
WASHER-HARD (10.2X20.5X2.5-MM THK)
|
16 | 126 |
| 4W-7395 |
ADAPTER
|
1 | 126 |
| 0S-1615 |
BOLT (1/4-20X0.75-IN)
|
4 | 127 |
| 0S-1571 |
BOLT (3/8-16X1.75-IN)
|
2 | 127 |
| 2D-7325 |
TEE-PIPE
|
1 | 127 |
| 3J-7354 |
SEAL-O-RING
|
2 | 127 |
| 3V-3308 |
WASHER-HARD (10.2X20.5X2.5-MM THK)
|
2 | 127 |
| 3P-0764 |
PLUG
|
1 | 127 |
| 4R-8605 |
ELBOW
|
1 | 127 |
| 4S-6399 |
CONNECTOR
|
2 | 127 |
| 5N-5646 |
HOSE AS
|
1 | 127 |
