| Part No. | Name | Qty | Page |
|---|---|---|---|
| 2H-3880 |
SCREW-DRIVE (#2X1/8)
|
2 | 715 |
| 5N-1782 |
PLATE-IDENTIFICATION (HYDROMECHANICAL SHUTOFF)
|
1 | 715 |
| 5N-6711 |
COVER
|
1 | 715 |
| 5N-2707 |
GASKET
|
1 | 715 |
| 5M-6213 |
PLUG-PIPE (1/4-18 NPTF THD)
|
6 | 715 |
| 5P-0537 |
WASHER (2MM THK)
|
22 | 715 |
| 5N-2709 |
BOLT (1/4-28X2.5 IN)
|
1 | 715 |
| 6F-0612 |
NUT-JAM (1/4-28 THD)
|
2 | 715 |
| 4F-7957 |
BOLT (1/4-20X.875IN)
|
3 | 715 |
| 5N-6443 |
VALVE GP-FUEL SHUTOFF
|
1 | 715 |
| 3D-4603 |
PLUG-PIPE (1/16-27 NPTF THD)
|
2 | 715 |
| 2A-4781 |
BOLT (1/4-20X2.75IN)
|
5 | 715 |
| 8S-4710 |
BOLT (1/4-20X4IN)
|
3 | 715 |
| 5N-4718 |
GASKET
|
1 | 715 |
| 5N-4727 |
COVER
|
1 | 715 |
| 5N-2725 |
GASKET
|
1 | 715 |
| 5N-2716 |
BOLT (1/4-28X1.1 IN)
|
1 | 715 |
| 172-0264 |
SEAT
|
1 | 715 |
| 5N-5297 |
SPRING
|
1 | 715 |
| 5N-4728 |
SEAT
|
1 | 715 |
| 6N-3504 |
SEAT-GOVERNOR SPRING
|
1 | 715 |
| 5N-5296 |
SPRING
|
1 | 715 |
| 5N-2718 |
VALVE GP-SPEED SENSING
|
1 | 715 |
| 6H-3958 |
BOLT-SOCKET HEAD (1/4-20X2.5IN)
|
1 | 715 |
| 6J-2819 |
BOLT-SOCKET HEAD (1/4-20X2.75IN)
|
7 | 715 |
| 5N-5990 |
VALVE GP-PRESSURE CONTROL
|
1 | 715 |
| 5N-6141 |
HOUSING AS-CONTROL
|
1 | 715 |
| 3N-5744 |
SHAFT-GOVERNOR CONTROL
|
1 | 715 |
| 3N-5755 |
LEVER
|
1 | 715 |
| 9F-2247 |
PLUG-PIPE
|
1 | 715 |
| 9L-9503 |
DOWEL-HOLLOW
|
2 | 715 |
| 172-0265 |
PUMP GP-GEROTOR
|
1 | 715 |
| 5N-3198 |
GASKET
|
1 | 715 |
| 3K-6168 |
BOLT-SOCKET HEAD (10-32X.625 IN)
|
8 | 715 |
| 5N-8227 |
GASKET
|
1 | 715 |
| 032-1267 |
CONNECTOR-FLARED
|
2 | 715 |
| 5N-4990 |
TUBE AS
|
1 | 715 |
| 3R-6569 |
BOLT (1/4-20X.875 IN)
|
1 | 715 |
| 032-1268 |
ELBOW (FLARED)
|
2 | 715 |
| 6K-9194 |
ELBOW (90 DEGREE)
|
1 | 715 |
| 3H-0240 |
WASHER-PLAIN (.8MM THK)
|
8 | 715 |
| 7K-4128 |
TEE-FLARED
|
1 | 715 |
| 2H-3880 |
SCREW-DRIVE (#2X1/8)
|
2 | 717 |
| 5N-1782 |
PLATE-IDENTIFICATION (HYDROMECHANICAL SHUTOFF)
|
1 | 717 |
| 5N-6711 |
COVER
|
1 | 717 |
| 5N-2707 |
GASKET
|
1 | 717 |
| 5M-6213 |
PLUG-PIPE (1/4-18 NPTF THD)
|
6 | 717 |
| 5P-0537 |
WASHER (2MM THK)
|
22 | 717 |
| 5N-2709 |
BOLT (1/4-28X2.5 IN)
|
1 | 717 |
| 6F-0612 |
NUT-JAM (1/4-28 THD)
|
2 | 717 |
