| Part No. | Name | Qty | Page |
|---|---|---|---|
| 4H-6112 |
BREATHER AS
|
1 | 616 |
| 4I-7464 |
GEAR (Z=25)
|
4 | 616 |
| 4I-7466 |
GEAR (Z=23)
|
4 | 616 |
| 4I-7467 |
GEAR (Z=72)
|
1 | 616 |
| 6V-7238 |
VALVE
|
1 | 616 |
| 7I-7728 |
CARRIER
|
1 | 616 |
| 7Y-0597 |
SPACER
|
1 | 616 |
| 7Y-1238 |
CARRIER
|
1 | 616 |
| 093-1730 |
RING
|
2 | 616 |
| 094-1509 |
SHAFT
|
4 | 616 |
| 094-1528 |
WASHER
|
8 | 616 |
| 095-1806 |
BEARING
|
1 | 616 |
| 096-2653 |
RING
|
1 | 616 |
| 096-4339 |
BEARING AS
|
1 | 616 |
| 110-7216 |
GEAR (Z=24)
|
1 | 616 |
| 114-1383 |
SHAFT
|
4 | 616 |
| 114-1398 |
GAUGE
|
1 | 616 |
| 114-1399 |
PIPE
|
1 | 616 |
| 114-1401 |
COVER
|
1 | 616 |
| 114-1403 |
CAGE
|
1 | 616 |
| 136-2802 |
CONNECTOR
|
2 | 616 |
| 136-2803 |
CLIP
|
2 | 616 |
| 169-5534 |
HOUSING
|
1 | 616 |
| 169-5535 |
GEAR (Z=20)
|
1 | 616 |
| 227-6108 |
SHAFT
|
1 | 616 |
| 227-6215 |
BOSS
|
1 | 616 |
| 296-6251 |
HOSE AS
|
1 | 616 |
| 093-1731 |
RING
|
1 | 616 |
| 094-0584 |
WASHER
|
8 | 616 |
| 094-1516 |
BEARING
|
4 | 616 |
| 095-0886 |
PIN
|
4 | 616 |
| 095-0891 |
PIN
|
4 | 616 |
| 135-9044 |
SEAL
|
2 | 616 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 616 |
| 5P-2235 |
SEAL - O - RING (ID=240.67mm)
|
1 | 616 |
| 7Y-0339 |
BEARING
|
8 | 616 |
| 7Y-0595 |
SPACER
|
1 | 616 |
| 7Y-1434 |
SPACER
|
1 | 616 |
| 8T-4183 |
BOLT (L=40mm)
|
8 | 616 |
| 8T-4223 |
WASHER
|
10 | 616 |
| 8T-4244 |
NUT
|
1 | 616 |
| 8T-4956 |
BOLT (L=35mm)
|
1 | 616 |
| 8T-6385 |
BOLT (L=180mm)
|
16 | 616 |
| 9X-8257 |
WASHER
|
16 | 616 |
| 1U-8846 |
GASKET MAKER (12ml)
|
1 | 616 |
