CAT 345D 239-1603 Parts Manual Diagram - LINES GP - BUCKET CYLINDER .................................................

Home › Parts Manual › CAT 345D › 239-1603

Part No.

239-1603

Name (EN)

LINES GP - BUCKET CYLINDER .................................................

Name (CN)

Qty

1 per assembly

Group

225-4527

System

HYDRAULIC SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 477 of official CAT 345D parts manual

Part No.	Name	Qty	Page
115-8694	LINES GP - BUCKET CYLINDER .................................................	1	477
225-4528	CYLINDER & SEAL GP - BUCKET..............................................	1	477
225-4531	CYLINDER & SEAL GP - BUCKET..............................................	1	477
