| Part No. | Name | Qty | Page |
|---|---|---|---|
| 142-6583 |
TUBE AS
|
1 | 522 |
| 100-4982 |
BOLT (L=45mm)
|
8 | 522 |
| 216-6539 |
HOSE AS
|
1 | 522 |
| 1P-3704 |
SEAL
|
3 | 522 |
| 3E-4062 |
CLIP
|
2 | 522 |
| 1P-3705 |
SEAL
|
3 | 522 |
| 6V-0757 |
GUARD (303cm)
|
1 | 522 |
| 1P-5767 |
FLANGE
|
4 | 522 |
| 161-1821 |
HOSE (221cm)
|
1 | 522 |
| 5P-8077 |
FLANGE
|
4 | 522 |
| 211-2653 |
STEM AS (STRAIGHT)
|
1 | 522 |
| 7X-2557 |
BOLT (L=140mm)
|
2 | 522 |
| 211-2658 |
STEM AS (90 )
|
1 | 522 |
| 8T-4121 |
WASHER
|
2 | 522 |
| 211-2659 |
SLEEVE
|
2 | 522 |
| 8T-4140 |
BOLT (L=60mm)
|
8 | 522 |
| 216-6540 |
HOSE AS
|
1 | 522 |
| 8T-4183 |
BOLT (L=40mm)
|
4 | 522 |
| 3E-4062 |
CLIP
|
2 | 522 |
| 8T-4193 |
BOLT (L=50mm)
|
4 | 522 |
| 6V-0752 |
GUARD (292cm)
|
1 | 522 |
| 8T-4194 |
BOLT (L=50mm)
|
8 | 522 |
| 161-1820 |
HOSE (210cm)
|
1 | 522 |
| 8T-4223 |
WASHER
|
8 | 522 |
| 153-0873 |
STEM AS (STRAIGHT)
|
1 | 522 |
| 8T-6685 |
BOLT (L=110mm)
|
2 | 522 |
| 153-0895 |
SLEEVE
|
2 | 522 |
| 277-0954 |
VALVE AS
|
1 | 522 |
| 292-7752 |
VALVE AS
|
1 | 522 |
| 294-6485 |
TUBE AS
|
1 | 522 |
| 306-1354 |
CLAMP
|
4 | 522 |
| 306-1355 |
CLAMP
|
4 | 522 |
| 9X-8257 |
WASHER H 9 8 6 7 9 E 13
|
18 | 522 |
