| Part No. | Name | Qty | Page |
|---|---|---|---|
| 281-3586 |
281-3586
|
1 | 101 |
| 3S-2093 |
STRAP
|
3 | 102 |
| 7I-2673 |
STRAP
|
3 | 102 |
| 096-4035 |
CLIP
|
1 | 102 |
| 111-4836 |
CLIP
|
2 | 102 |
| 230-2781 |
HOSE
|
1 | 102 |
| 230-2782 |
HOSE
|
1 | 102 |
| 230-2793 |
SHROUD AS
|
1 | 102 |
| 230-2835 |
PIPE AS
|
1 | 102 |
| 230-2854 |
HOSE
|
1 | 102 |
| 245-9206 |
TANK AS
|
1 | 102 |
| 171-3370 |
CAP AS
|
1 | 102 |
| 204-0920 |
CAP AS
|
1 | 102 |
| 281-3586 |
RADIATOR GP
|
1 | 102 |
| 281-3616 |
BAND AS
|
1 | 102 |
| 281-3619 |
BRACKET AS
|
1 | 102 |
| 281-3622 |
PLATE
|
1 | 102 |
| 7Y-1976 |
HOSE (52cm)
|
1 | 102 |
| 6V-5386 |
CLIP
|
1 | 102 |
| 7X-2563 |
BOLT (L=60mm)
|
4 | 102 |
| 7X-7729 |
WASHER
|
5 | 102 |
| 8T-4121 |
WASHER
|
6 | 102 |
| 8T-4123 |
WASHER
|
4 | 102 |
| 8T-4136 |
BOLT (L=25mm)
|
24 | 102 |
| 8T-4137 |
BOLT (L=20mm)
|
2 | 102 |
| 5P-5649 |
SEAL (1.09m)
|
1 | 102 |
| 8T-4192 |
BOLT (L=25mm)
|
1 | 102 |
| 8T-4195 |
BOLT (L=30mm)
|
5 | 102 |
| 8T-4222 |
WASHER
|
20 | 102 |
| 8T-4223 |
WASHER
|
1 | 102 |
| 9D-3769 |
GROMMET
|
1 | 102 |
