| Part No. | Name | Qty | Page |
|---|---|---|---|
| 125-1302 |
125-1302
|
1 | 171 |
| 3E-8320 |
PLATE (INSTRUCTION)
|
1 | 172 |
| 7N-0719 |
SWITCH AS (DISCONNECT)
|
1 | 172 |
| 121-1023 |
BLOCK
|
1 | 172 |
| 125-1302 |
SWITCH AS (START RELAY)
|
1 | 172 |
| 171-2212 |
BREAKER AS
|
1 | 172 |
| 253-2111 |
LOCKWASHER
|
2 | 172 |
| 6V-8187 |
NUT
|
2 | 172 |
| 8T-4205 |
WASHER
|
2 | 172 |
| 224-2908 |
BRACKET AS
|
1 | 172 |
| 234-1034 |
CABLE AS
|
1 | 172 |
| 9G-4343 |
TERMINAL
|
2 | 172 |
| 234-1036 |
CABLE AS
|
1 | 172 |
| 9G-4343 |
TERMINAL
|
2 | 172 |
| 234-1037 |
WIRE AS
|
1 | 172 |
| 2L-8050 |
TERMINAL
|
2 | 172 |
| 234-1038 |
WIRE AS
|
1 | 172 |
| 2L-8050 |
TERMINAL
|
2 | 172 |
| 238-1506 |
COVER
|
1 | 172 |
| 238-2280 |
WIRE AS
|
1 | 172 |
| 2L-8050 |
TERMINAL
|
2 | 172 |
| 238-2392 |
BUS
|
1 | 172 |
| 171-2210 |
BREAKER AS
|
1 | 172 |
| 253-2111 |
LOCKWASHER
|
2 | 172 |
| 6V-8187 |
NUT
|
2 | 172 |
| 8T-4205 |
WASHER
|
2 | 172 |
| 5C-9553 |
BOLT (L=16mm)
|
5 | 172 |
| 5P-4115 |
WASHER
|
4 | 172 |
| 6V-5645 |
SCREW
|
4 | 172 |
| 8T-0328 |
WASHER
|
4 | 172 |
| 8T-4171 |
BOLT (L=12mm)
|
4 | 172 |
| 8T-4970 |
BOLT (L=14mm)
|
4 | 172 |
| 9X-8256 |
WASHER
|
9 | 172 |
| 2H-3922 |
LOCKWASHER
|
1 | 173 |
| 8H-5303 |
NUT
|
1 | 173 |
| 9F-5644 |
LOCKWASHER
|
2 | 173 |
| 6F-7045 |
NUT
|
2 | 173 |
| 8H-5306 |
KEY
|
1 | 173 |
