| Part No. | Name | Qty | Page |
|---|---|---|---|
| 9F-2167 |
SCREW
|
4 | 470 |
| 124-1107 |
GROMMET
|
3 | 470 |
| 129-5874 |
GROMMET
|
14 | 470 |
| 138-5708 |
CLIP
|
4 | 470 |
| 138-5709 |
GROMMET
|
3 | 470 |
| 199-1875 |
GROMMET
|
2 | 470 |
| 212-5357 |
HOSE AS
|
1 | 470 |
| 161-1837 |
HOSE (171cm)
|
1 | 470 |
| 212-5537 |
HOSE AS
|
1 | 470 |
| 161-1821 |
HOSE (167cm)
|
1 | 470 |
| 211-2653 |
STEM AS (STRAIGHT)
|
1 | 470 |
| 211-2658 |
STEM AS (90 )
|
1 | 470 |
| 211-2659 |
SLEEVE
|
2 | 470 |
| 245-5099 |
TUBE AS
|
1 | 470 |
| 245-5100 |
TUBE AS
|
1 | 470 |
| 248-9789 |
TUBE AS
|
1 | 470 |
| 248-9790 |
TUBE AS
|
1 | 470 |
| 255-1644 |
TUBE AS
|
1 | 470 |
| 255-1645 |
TUBE AS
|
1 | 470 |
| 255-1646 |
TUBE AS
|
2 | 470 |
| 096-9986 |
BOLT (L=55mm)
|
18 | 470 |
| 124-1106 |
CLIP
|
4 | 470 |
| 124-1108 |
CLIP
|
20 | 470 |
| 124-1109 |
CLIP
|
6 | 470 |
| 1P-3703 |
SEAL
|
8 | 470 |
| 1P-3704 |
SEAL
|
4 | 470 |
| 1P-3705 |
SEAL
|
2 | 470 |
| 1P-5767 |
FLANGE
|
8 | 470 |
| 5P-0047 |
COVER
|
4 | 470 |
| 5P-0048 |
COVER
|
2 | 470 |
| 5P-8077 |
FLANGE
|
4 | 470 |
| 6V-0400 |
FLANGE
|
8 | 470 |
| 7X-2554 |
BOLT (L=70mm)
|
4 | 470 |
| 8T-4139 |
BOLT (L=30mm)
|
16 | 470 |
| 8T-4140 |
BOLT (L=60mm)
|
12 | 470 |
| 8T-4184 |
BOLT (L=45mm)
|
8 | 470 |
| 8T-4194 |
BOLT (L=50mm)
|
32 | 470 |
| 8T-4223 |
WASHER
|
58 | 470 |
| 9X-8257 |
WASHER
|
16 | 470 |
