| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 143-4237 |
TUBE AS
|
1 | 483 |
| 143-4238 |
TUBE AS
|
1 | 483 |
| 1P-3704 |
SEAL
|
4 | 483 |
| 1P-5767 |
FLANGE
|
8 | 483 |
| 8T-4223 |
WASHER
|
58 | 483 |
| 8T-4194 |
BOLT (L=50mm)
|
20 | 483 |
| 151-5449 |
HOSE AS
|
1 | 483 |
| 5P-6450 |
STEM AS (STRAIGHT)
|
2 | 483 |
| 5P-8285 |
HOSE (171cm)
|
1 | 483 |
| 5P-6449 |
SLEEVE
|
2 | 483 |
| 187-6781 |
HOSE AS
|
1 | 483 |
| 5P-8814 |
HOSE (166cm)
|
1 | 483 |
| 162-6483 |
STEM AS (90 )
|
1 | 483 |
| 162-3077 |
SLEEVE
|
2 | 483 |
| 162-6480 |
STEM AS (STRAIGHT)
|
1 | 483 |
| 134-6789 |
TUBE AS
|
2 | 483 |
| 5K-9090 |
SEAL - O - RING (OD=27.22mm)
|
4 | 483 |
| 134-6791 |
TUBE AS
|
1 | 483 |
| 134-6792 |
TUBE AS
|
1 | 483 |
| 1P-3705 |
SEAL
|
2 | 483 |
| 5P-8077 |
FLANGE
|
4 | 483 |
| 9X-8257 |
WASHER
|
16 | 483 |
| 8T-4193 |
BOLT (L=50mm)
|
4 | 483 |
| 8T-4140 |
BOLT (L=60mm)
|
4 | 483 |
| 143-4239 |
TUBE AS
|
1 | 483 |
| 143-4240 |
TUBE AS
|
1 | 483 |
| 143-4158 |
CLIP
|
6 | 483 |
| 8T-4910 |
BOLT (L=60mm)
|
14 | 483 |
| 143-4156 |
CLIP
|
4 | 483 |
| 7X-2554 |
BOLT (L=70mm)
|
8 | 483 |
| 143-4157 |
CLIP
|
2 | 483 |
| 143-4160 |
CLIP
|
2 | 483 |
| 143-4159 |
CLIP
|
20 | 483 |
| 5P-0048 |
COVER
|
2 | 483 |
| 8T-4184 |
BOLT (L=45mm)
|
24 | 483 |
| 6V-0400 |
FLANGE
|
8 | 483 |
| 9F-2167 |
SCREW
|
4 | 483 |
| 5P-0047 |
COVER
|
4 | 483 |
| 1P-3703 |
SEAL
|
4 | 483 |
