| Part No. | Name | Qty | Page |
|---|---|---|---|
| 085-6455 |
085-6455
|
1 | 542 |
| 124-1008 |
GUARD
|
1 | 543 |
| 7K-1181 |
STRAP
|
15 | 543 |
| 104-8774 |
HOSE AS (NOM 06, L=2200mm)
|
1 | 543 |
| 104-8771 |
HOSE AS (NOM 06, L=2430mm)
|
1 | 543 |
| 7Y-4193 |
HOSE AS (NOM 06, L=2500mm)
|
3 | 543 |
| 4I-3991 |
HOSE AS (NOM 06, L=2100mm)
|
1 | 543 |
| 6V-9001 |
ELBOW
|
14 | 543 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
16 | 543 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
32 | 543 |
| 6V-8724 |
ELBOW
|
2 | 543 |
| 8T-5041 |
BOLT (L=120mm)
|
2 | 543 |
| 8T-4223 |
WASHER
|
6 | 543 |
| 131-9587 |
SUPPORT AS
|
1 | 543 |
| 8T-4956 |
BOLT (L=35mm)
|
4 | 543 |
| 085-6455 |
VALVE GP
|
1 | 543 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 543 |
| 4I-9522 |
BAND (L2,YELLOW)
|
4 | 543 |
| 4I-9523 |
BAND (L3,BLUE)
|
4 | 543 |
| 4I-9524 |
BAND (L4,BROWN)
|
4 | 543 |
| 4I-9525 |
BAND (R1,ORANGE)
|
4 | 543 |
| 4I-9526 |
BAND (R2,WHITE)
|
4 | 543 |
| 4I-9527 |
BAND (R3,GREEN)
|
4 | 543 |
| 4I-9528 |
BAND (R4,PURPLE)
|
4 | 543 |
| 115-8645 |
GUARD
|
2 | 543 |
| 7I-8252 |
HOSE AS (NOM 06, L=2350mm)
|
2 | 543 |
| 4I-3981 |
HOSE AS (NOM 06, L=2750mm)
|
2 | 543 |
| 4I-0833 |
HOSE AS (NOM 06, L=1850mm)
|
1 | 543 |
| 4I-0812 |
HOSE AS (NOM 06, L=2650mm)
|
1 | 543 |
| 104-8976 |
HOSE AS (NOM 06, L=1900mm)
|
1 | 543 |
| 4I-1634 |
HOSE AS (NOM 06, L=2900mm)
|
1 | 543 |
| 7Y-4199 |
HOSE AS (NOM 06, L=1800mm)
|
1 | 543 |
| 4I-6003 |
HOSE AS (NOM 06, L=2650mm)
|
1 | 543 |
| 085-6455 |
085-6455
|
1 | 544 |
| 124-1008 |
GUARD
|
2 | 545 |
| 7K-1181 |
STRAP
|
17 | 545 |
| 104-8774 |
HOSE AS (NOM 06, L=2200mm)
|
1 | 545 |
| 104-8771 |
HOSE AS (NOM 06, L=2430mm)
|
1 | 545 |
| 7Y-4193 |
HOSE AS (NOM 06, L=2500mm)
|
3 | 545 |
| 4I-3991 |
HOSE AS (NOM 06, L=2100mm)
|
1 | 545 |
| 6V-9001 |
ELBOW
|
14 | 545 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
16 | 545 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
32 | 545 |
| 6V-8724 |
ELBOW
|
2 | 545 |
| 7X-2549 |
BOLT (L=100mm)
|
2 | 545 |
| 8T-4223 |
WASHER
|
6 | 545 |
| 131-9587 |
SUPPORT AS
|
1 | 545 |
| 8T-4956 |
BOLT (L=35mm)
|
4 | 545 |
| 085-6455 |
VALVE GP
|
1 | 545 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 545 |
