| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 239-1610 |
239-1610
|
1 | 502 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
8 | 503 |
| 5I-4390 |
HOSE AS
|
1 | 503 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
1 | 503 |
| 5P-5148 |
STRAP
|
4 | 503 |
| 7K-1181 |
STRAP
|
4 | 503 |
| 111-6746 |
HOSE AS
|
1 | 503 |
| 176-4770 |
HOSE AS
|
1 | 503 |
| 260-8078 |
GUARD
|
2 | 503 |
| 269-9775 |
HOSE AS
|
1 | 503 |
| 275-1731 |
FITTING
|
1 | 503 |
| 6V-8637 |
CONNECTOR
|
2 | 503 |
| 6V-8639 |
CONNECTOR
|
1 | 503 |
| 6V-9007 |
ELBOW
|
1 | 503 |
| 6V-9002 |
ELBOW
|
2 | 503 |
| 6V-9876 |
ELBOW
|
1 | 503 |
| 6V-8721 |
ELBOW
|
1 | 503 |
| 9S-4185 |
PLUG
|
1 | 503 |
| 6V-8775 |
TEE
|
1 | 503 |
| 6V-9004 |
ELBOW
|
1 | 503 |
| 115-8634 |
TEE
|
1 | 503 |
| 165-3260 |
PIPE AS
|
1 | 503 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
5 | 503 |
| 5P-7464 |
CLIP
|
1 | 503 |
| 5P-7465 |
CLIP
|
1 | 503 |
| 6J-2680 |
SEAL - O - RING (ID=69.44mm)
|
1 | 503 |
| 8T-4139 |
BOLT (L=30mm)
|
1 | 503 |
| 8T-4223 |
WASHER
|
5 | 503 |
| 8T-4956 |
BOLT (L=35mm)
|
4 | 503 |
| 8T-2920 |
GROMMET
|
1 | 503 |
| 2M-9780 |
SEAL - O - RING (ID=19.18mm)
|
2 | 503 |
| 6V-9746 |
SEAL - O - RING (OD=22.50mm)
|
4 | 503 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
6 | 503 |
| 239-1610 |
239-1610
|
1 | 493 |
| 6V-8398 |
SEAL - O - RING (OD=16.03mm)
|
9 | 494 |
| 5I-4390 |
HOSE AS
|
1 | 494 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
1 | 494 |
| 5P-5148 |
STRAP
|
2 | 494 |
| 7K-1181 |
STRAP
|
10 | 494 |
| 275-1361 |
HOSE AS
|
1 | 494 |
| 176-4770 |
HOSE AS
|
1 | 494 |
| 282-7106 |
GROMMET
|
2 | 494 |
| 269-9775 |
HOSE AS
|
1 | 494 |
| 275-1731 |
FITTING
|
1 | 494 |
| 6V-8637 |
CONNECTOR
|
1 | 494 |
| 6V-8639 |
CONNECTOR
|
1 | 494 |
| 6V-9007 |
ELBOW
|
1 | 494 |
| 6V-9002 |
ELBOW
|
2 | 494 |
| 6V-9876 |
ELBOW
|
1 | 494 |
| 6V-8721 |
ELBOW
|
1 | 494 |
