| Part No. | Name | Qty | Page |
|---|---|---|---|
| 174-9570 |
174-9570
|
1 | 116 |
| 165-9154 |
165-9154
|
1 | 116 |
| 239-2396 |
239-2396
|
1 | 116 |
| 4I-0379 |
VALVE
|
1 | 117 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
4 | 117 |
| 4N-9624 |
ADAPTER
|
1 | 117 |
| 5P-1442 |
HOSE (567.5cm)
|
1 | 117 |
| 7Y-8165 |
GROMMET
|
1 | 117 |
| 5P-1442 |
HOSE (39cm)
|
1 | 117 |
| 9Y-8389 |
GASKET
|
1 | 117 |
| 003-7764 |
END
|
2 | 117 |
| 095-1386 |
CLAMP
|
8 | 117 |
| 134-6852 |
CONNECTOR
|
1 | 117 |
| 8T-4139 |
BOLT (L=30mm)
|
4 | 117 |
| 139-6873 |
VALVE GP
|
1 | 117 |
| 5P-4924 |
ELBOW
|
2 | 117 |
| 197-8391 |
SENSOR GP
|
1 | 117 |
| 212-2768 |
SWITCH GP (PRESSURE)
|
1 | 117 |
| 237-9312 |
BASE AS
|
1 | 117 |
| 9S-4167 |
STUD
|
1 | 117 |
| 239-2396 |
SENSOR GP
|
1 | 117 |
| 241-2374 |
HOSE AS
|
1 | 117 |
| 241-2375 |
HOSE AS
|
1 | 117 |
| 241-2376 |
HOSE AS
|
1 | 117 |
| 262-2598 |
SUPPORT AS
|
1 | 117 |
| 005-4362 |
ELBOW
|
1 | 117 |
| 8T-1715 |
ADAPTER
|
1 | 117 |
| 6V-8634 |
CONNECTOR
|
1 | 117 |
| 6V-8636 |
CONNECTOR
|
1 | 117 |
| 6V-8724 |
ELBOW
|
1 | 117 |
| 8T-1683 |
ELBOW
|
1 | 117 |
| 165-9154 |
PUMP GP
|
1 | 117 |
| 1R-0762 |
FILTER AS
|
1 | 117 |
| 2D-1290 |
GROMMET
|
3 | 117 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
9 | 117 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
4 | 117 |
| 5K-8451 |
CLIP
|
17 | 117 |
| 6V-4589 |
SEAL - O - RING (ID=19.18mm)
|
1 | 117 |
| 6V-7357 |
BOLT (L=25mm)
|
1 | 117 |
| 8L-2786 |
SEAL - O - RING (ID=16.36mm)
|
3 | 117 |
| 8T-4121 |
WASHER
|
28 | 117 |
| 8T-4133 |
NUT
|
1 | 117 |
| 8T-4136 |
BOLT (L=25mm)
|
7 | 117 |
| 8T-4137 |
BOLT (L=20mm)
|
14 | 117 |
| 8T-4195 |
BOLT (L=30mm)
|
4 | 117 |
| 8T-4196 |
BOLT (L=35mm)
|
2 | 117 |
| 8T-4224 |
WASHER
|
1 | 117 |
| 8T-4908 |
BOLT (L=25mm)
|
1 | 117 |
| 9M-8406 |
CLIP
|
7 | 117 |
| 9S-8004 |
PLUG
|
5 | 117 |
