| Part No. | Name | Qty | Page |
|---|---|---|---|
| 295-9674 |
295-9674
|
1 | 405 |
| 225-4518 |
VALVE GP
|
1 | 406 |
| 274-2490 |
PUMP GP
|
1 | 406 |
| 247-8841 |
BOLT (L=30mm)
|
2 | 406 |
| 246-9867 |
SEAL
|
1 | 406 |
| 7Y-4359 |
SCREW
|
2 | 406 |
| 295-9674 |
295-9674
|
1 | 407 |
| 206-9291 |
SEAL - O - RING (ID=9.80mm)
|
2 | 408 |
| 295-9659 |
BLOCK
|
1 | 408 |
| 242-6920 |
BOLT (L=30mm)
|
8 | 408 |
| 295-9657 |
BARREL AS
|
1 | 408 |
| 247-8985 |
DOWEL
|
4 | 408 |
| 249-1307 |
BOLT (L=95mm)
|
2 | 408 |
| 247-8729 |
COVER
|
2 | 408 |
| 247-8713 |
BEARING
|
1 | 408 |
| 242-6919 |
SETSCREW
|
2 | 408 |
| 8T-9080 |
BOLT (L=20mm)
|
8 | 408 |
| 8T-4131 |
NUT
|
2 | 408 |
| 225-4516 |
PLATE
|
1 | 408 |
| 6V-8200 |
BOLT (L=35mm)
|
8 | 408 |
| 249-6670 |
SEAL - O - RING (ID=169.30mm)
|
1 | 408 |
| 7I-8166 |
STOPPER
|
2 | 408 |
| 247-8720 |
SPACER
|
2 | 408 |
| 109-1296 |
SEAL - O - RING (ID=39.40mm)
|
2 | 408 |
| 247-8717 |
SPACER
|
2 | 408 |
| 7I-8172 |
RING
|
2 | 408 |
| 095-0929 |
RING
|
2 | 408 |
| 242-6914 |
PISTON
|
2 | 408 |
| 247-8726 |
COVER
|
1 | 408 |
| 247-8712 |
PIN AS
|
2 | 408 |
| 7I-8152 |
SPRING
|
18 | 408 |
| 109-1294 |
SEAL - O - RING (ID=20.80mm)
|
2 | 408 |
| 7I-8171 |
RING
|
2 | 408 |
| 242-6915 |
STOPPER
|
2 | 408 |
| 095-0965 |
PLUG
|
11 | 408 |
| 095-0966 |
PLUG
|
2 | 408 |
| 242-6918 |
NUT
|
2 | 408 |
| 200-3292 |
SETSCREW
|
2 | 408 |
| 264-8266 |
BOLT (L=130mm)
|
1 | 408 |
| 234-4539 |
DOWEL
|
2 | 408 |
| 249-1306 |
BOLT (L=60mm)
|
10 | 408 |
| 242-6916 |
GASKET
|
2 | 408 |
| 110-5525 |
PLUG
|
4 | 408 |
| 153-4906 |
SEAL - O - RING (ID=11.89mm)
|
4 | 408 |
| 295-9656 |
PISTON AS
|
2 | 408 |
| 7I-8154 |
PLATE
|
2 | 408 |
| 242-6912 |
PLATE
|
2 | 408 |
| 242-6913 |
RETAINER
|
2 | 408 |
| 289-8172 |
SWASHPLATE AS
|
2 | 408 |
| 7I-8084 |
PLUG
|
20 | 408 |
