| Part No. | Name | Qty | Page |
|---|---|---|---|
| 255-5768 |
255-5768
|
1 | 536 |
| 171-0188 |
171-0188
|
1 | 536 |
| 4I-0806 |
HOSE AS (NOM 06, L=1700mm)
|
1 | 537 |
| 7X-2549 |
BOLT (L=100mm)
|
2 | 537 |
| 4I-3941 |
FITTING AS
|
1 | 537 |
| 8T-4121 |
WASHER
|
12 | 537 |
| 4I-6054 |
HOSE AS (NOM 06, L=2350mm)
|
1 | 537 |
| 8T-4136 |
BOLT (L=25mm)
|
6 | 537 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 537 |
| 8T-4137 |
BOLT (L=20mm)
|
1 | 537 |
| 4I-9522 |
BAND (L2,YELLOW)
|
4 | 537 |
| 8T-4177 |
BOLT (L=90mm)
|
4 | 537 |
| 4I-9523 |
BAND (L3,BLUE)
|
8 | 537 |
| 8T-4185 |
BOLT (L=50mm)
|
2 | 537 |
| 4I-9524 |
BAND (L4,BROWN)
|
4 | 537 |
| 8T-4192 |
BOLT (L=25mm)
|
4 | 537 |
| 4I-9525 |
BAND (R1,ORANGE)
|
4 | 537 |
| 8T-4195 |
BOLT (L=30mm)
|
1 | 537 |
| 4I-9527 |
BAND (R3,GREEN)
|
8 | 537 |
| 8T-4223 |
WASHER
|
8 | 537 |
| 7K-1181 |
STRAP
|
19 | 537 |
| 8T-4224 |
WASHER
|
4 | 537 |
| 7Y-4387 |
HOSE AS (NOM 06, L=2600mm)
|
1 | 537 |
| 8T-4956 |
BOLT (L=35mm)
|
2 | 537 |
| 087-5306 |
HOSE AS (NOM 06, L=2015mm)
|
1 | 537 |
| 8T-6870 |
BOLT (L=70mm)
|
4 | 537 |
| 087-6583 |
HOSE AS (NOM 06, L=2530mm)
|
1 | 537 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
25 | 537 |
| 104-8783 |
HOSE AS (NOM 06, L=2150mm)
|
2 | 537 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
31 | 537 |
| 087-5774 |
HOSE AS (NOM 06, L=1060mm)
|
1 | 537 |
| 8B-6561 |
SPACER
|
1 | 537 |
| 087-5780 |
HOSE AS (NOM 06, L=2550mm)
|
1 | 537 |
| 8T-4178 |
BOLT (L=90mm)
|
1 | 537 |
| 134-6921 |
HOSE AS (NOM 06, L=3950mm)
|
1 | 537 |
| 8T-4182 |
BOLT (L=45mm)
|
1 | 537 |
| 136-0207 |
STRAP
|
4 | 537 |
| 199-1948 |
HOSE AS (NOM 06, L=4650mm)
|
1 | 537 |
| 255-1826 |
SPACER
|
2 | 537 |
| 255-1900 |
SUPPORT AS
|
1 | 537 |
| 260-8148 |
PLATE
|
1 | 537 |
| 266-1158 |
SUPPORT AS
|
1 | 537 |
| 275-1442 |
CLIP
|
4 | 537 |
| 275-1443 |
CLIP
|
4 | 537 |
| 275-1444 |
GROMMET
|
4 | 537 |
| 275-1678 |
SUPPORT AS
|
1 | 537 |
| 275-1681 |
HOSE AS (NOM 06, L=1800mm)
|
1 | 537 |
| 275-1684 |
HOSE AS (NOM 06, L=1670mm)
|
1 | 537 |
| 275-1687 |
HOSE AS (NOM 06, L=2000mm)
|
1 | 537 |
| 275-1690 |
HOSE AS (NOM 06, L=2850mm)
|
1 | 537 |
