| Part No. | Name | Qty | Page |
|---|---|---|---|
| 3B-8489 |
FITTING
|
5 | 800 |
| 093-0349 |
WASHER
|
1 | 800 |
| 166-1496 |
SEAL
|
4 | 800 |
| 189-3922 |
PIN
|
1 | 800 |
| 201-2771 |
WASHER (OD=90.00mm)
|
1 | 800 |
| 201-2836 |
BOLT (L=200mm)
|
1 | 800 |
| 8T-5460 |
BOLT (L=40mm)
|
1 | 800 |
| 251-2552 |
PIN AS
|
1 | 800 |
| 251-2557 |
PIN
|
1 | 800 |
| 251-2558 |
PIN AS
|
1 | 800 |
| 279-2677 |
LINK AS
|
1 | 800 |
| 093-1345 |
SEAL - O - RING (ID=155.00mm)
|
2 | 800 |
| 093-1349 |
SEAL - O - RING (ID=175.00mm)
|
2 | 800 |
| 166-1488 |
SHIM (T=2.00mm)
|
2 | 800 |
| 166-1495 |
SEAL
|
2 | 800 |
| 186-5649 |
BOLT (L=160mm)
|
1 | 800 |
| 8T-4001 |
NUT
|
2 | 800 |
| 8T-4123 |
WASHER
|
1 | 800 |
| 8T-4131 |
NUT
|
2 | 800 |
| 8T-4167 |
WASHER
|
1 | 800 |
| 8T-5379 |
BOLT (L=50mm)
|
1 | 800 |
| 241-7140 |
LINK AS
|
1 | 800 |
| 241-7280 |
BEARING
|
2 | 800 |
| 228-5615 |
BEARING
|
2 | 800 |
