| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 255-5866 |
255-5866
|
1 | 435 |
| 4I-9521 |
BAND (L1,RED)
|
2 | 436 |
| 4I-9522 |
BAND (L2,YELLOW)
|
2 | 436 |
| 4I-9525 |
BAND (R1,ORANGE)
|
2 | 436 |
| 4I-9526 |
BAND (R2,WHITE)
|
2 | 436 |
| 7K-1181 |
STRAP
|
22 | 436 |
| 108-7550 |
CLIP
|
4 | 436 |
| 115-8856 |
SUPPORT AS
|
2 | 436 |
| 149-1738 |
CLIP
|
4 | 436 |
| 207-6228 |
TUBE AS
|
1 | 436 |
| 207-6229 |
TUBE AS
|
1 | 436 |
| 223-7098 |
PIPE AS
|
1 | 436 |
| 223-7100 |
SUPPORT AS
|
1 | 436 |
| 223-7103 |
PIPE AS
|
1 | 436 |
| 223-7105 |
SUPPORT AS
|
1 | 436 |
| 245-5110 |
HOSE AS
|
2 | 436 |
| 245-5113 |
HOSE AS
|
2 | 436 |
| 245-5116 |
HOSE AS
|
2 | 436 |
| 245-5120 |
SUPPORT AS
|
1 | 436 |
| 245-5122 |
BLOCK
|
1 | 436 |
| 260-8278 |
HOSE AS
|
2 | 436 |
| 270-5692 |
VALVE GP
|
1 | 436 |
| 6V-8636 |
CONNECTOR
|
8 | 436 |
| 6V-8713 |
CONNECTOR
|
4 | 436 |
| 6V-9007 |
ELBOW
|
1 | 436 |
| 6V-9200 |
ELBOW
|
2 | 436 |
| 6V-8724 |
ELBOW
|
4 | 436 |
| 9S-4185 |
PLUG
|
1 | 436 |
| 1P-3703 |
SEAL
|
2 | 436 |
| 1P-3704 |
SEAL
|
2 | 436 |
| 5K-9090 |
SEAL - O - RING (OD=27.22mm)
|
2 | 436 |
| 7J-9108 |
SEAL - O - RING (OD=19.28mm)
|
6 | 436 |
| 8T-4121 |
WASHER
|
10 | 436 |
| 8T-4139 |
BOLT (L=30mm)
|
8 | 436 |
| 8T-4176 |
BOLT (L=90mm)
|
2 | 436 |
| 8T-4185 |
BOLT (L=50mm)
|
2 | 436 |
| 8T-4196 |
BOLT (L=35mm)
|
8 | 436 |
| 8T-4223 |
WASHER
|
10 | 436 |
| 8T-4648 |
BOLT (L=70mm)
|
8 | 436 |
| 8T-4910 |
BOLT (L=60mm)
|
8 | 436 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
12 | 436 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
14 | 436 |
| 3D-2824 |
SEAL - O - RING (ID=23.47mm)
|
5 | 436 |
| 6V-9746 |
SEAL - O - RING (OD=22.50mm)
|
1 | 436 |
| 3J-7354 |
SEAL - O - RING (ID=8.92mm)
|
2 | 436 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
1 | 436 |
