| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 3B-8489 |
FITTING
|
4 | 815 |
| 5B-0651 |
FITTING
|
1 | 815 |
| 093-1347 |
SEAL - O - RING (ID=200.00mm)
|
2 | 815 |
| 195-5479 |
PLATE
|
1 | 815 |
| 201-2771 |
WASHER (OD=90.00mm)
|
2 | 815 |
| 212-3095 |
PLATE
|
1 | 815 |
| 235-7626 |
LINK AS
|
1 | 815 |
| 235-7627 |
LINK
|
1 | 815 |
| 235-7628 |
PIN AS
|
1 | 815 |
| 235-7636 |
PIN AS
|
1 | 815 |
| 235-7639 |
PIN AS
|
1 | 815 |
| 235-7642 |
PIN AS
|
1 | 815 |
| 9X-8257 |
WASHER
|
6 | 815 |
| 9X-4597 |
SEAL
|
6 | 815 |
| 093-1345 |
SEAL - O - RING (ID=155.00mm)
|
2 | 815 |
| 7X-2553 |
BOLT (L=40mm)
|
6 | 815 |
| 8T-4167 |
WASHER
|
2 | 815 |
| 8T-5379 |
BOLT (L=50mm)
|
2 | 815 |
| 235-7759 |
LINK AS
|
1 | 815 |
| 087-5548 |
BEARING
|
2 | 815 |
| 7Y-2397 |
BEARING
|
2 | 815 |
| 3B-8489 |
FITTING
|
4 | 798 |
| 5B-0651 |
FITTING
|
1 | 798 |
| 093-1347 |
SEAL - O - RING (ID=200.00mm)
|
2 | 798 |
| 195-5479 |
PLATE
|
1 | 798 |
| 201-2771 |
WASHER (OD=90.00mm)
|
2 | 798 |
| 212-3095 |
PLATE
|
1 | 798 |
| 235-7626 |
LINK AS
|
1 | 798 |
| 235-7627 |
LINK
|
1 | 798 |
| 235-7628 |
PIN AS
|
1 | 798 |
| 235-7636 |
PIN AS
|
1 | 798 |
| 235-7639 |
PIN AS
|
1 | 798 |
| 235-7642 |
PIN AS
|
1 | 798 |
| 9X-8257 |
WASHER
|
6 | 798 |
| 9X-4597 |
SEAL
|
6 | 798 |
| 093-1345 |
SEAL - O - RING (ID=155.00mm)
|
2 | 798 |
| 7X-2553 |
BOLT (L=40mm)
|
6 | 798 |
| 8T-4167 |
WASHER
|
2 | 798 |
| 8T-5379 |
BOLT (L=50mm)
|
2 | 798 |
| 235-7759 |
LINK AS
|
1 | 798 |
| 087-5548 |
BEARING
|
2 | 798 |
| 7Y-2397 |
BEARING
|
2 | 798 |
