| 零件号 | 零件名称 | 数量 | 页码 |
|---|---|---|---|
| 4I-2187 |
SUPPORT AS
|
1 | 329 |
| 236-3669 |
LOCK AS
|
1 | 329 |
| 236-3670 |
STRIKER AS
|
1 | 329 |
| 236-3671 |
SEAL
|
1 | 329 |
| 236-9435 |
BOX AS
|
1 | 329 |
| 3D-9143 |
HINGE
|
2 | 329 |
| 236-9438 |
PLUNGER AS
|
1 | 329 |
| 236-9440 |
SHEET
|
1 | 329 |
| 273-7964 |
MOUNT
|
2 | 329 |
| 278-3581 |
CUSHION
|
4 | 329 |
| 095-0843 |
COTTER
|
1 | 329 |
| 096-3780 |
PIN
|
1 | 329 |
| 105-3487 |
BOLT (L=20mm)
|
4 | 329 |
| 170-9360 |
GROMMET
|
1 | 329 |
| 5C-9553 |
BOLT (L=16mm)
|
3 | 329 |
| 5P-1075 |
WASHER
|
4 | 329 |
| 5P-4116 |
WASHER
|
1 | 329 |
| 8T-4133 |
NUT
|
4 | 329 |
| 8T-4200 |
BOLT (L=16mm)
|
2 | 329 |
| 8T-4224 |
WASHER
|
2 | 329 |
| 9X-8256 |
WASHER
|
7 | 329 |
| 8T-4223 |
WASHER
|
2 | 329 |
| 4I-2187 |
SUPPORT AS
|
1 | 322 |
| 236-3669 |
LOCK AS
|
1 | 322 |
| 236-3670 |
STRIKER AS
|
1 | 322 |
| 236-3671 |
SEAL
|
1 | 322 |
| 236-9435 |
BOX AS
|
1 | 322 |
| 3D-9143 |
HINGE
|
2 | 322 |
| 236-9438 |
PLUNGER AS
|
1 | 322 |
| 236-9440 |
SHEET
|
1 | 322 |
| 273-7964 |
MOUNT
|
2 | 322 |
| 278-3581 |
CUSHION
|
4 | 322 |
| 095-0843 |
COTTER
|
1 | 322 |
| 096-3780 |
PIN
|
1 | 322 |
| 105-3487 |
BOLT (L=20mm)
|
4 | 322 |
| 170-9360 |
GROMMET
|
1 | 322 |
| 5C-9553 |
BOLT (L=16mm)
|
3 | 322 |
| 5P-1075 |
WASHER
|
4 | 322 |
| 5P-4116 |
WASHER
|
1 | 322 |
| 8T-4133 |
NUT
|
4 | 322 |
| 8T-4200 |
BOLT (L=16mm)
|
2 | 322 |
| 8T-4224 |
WASHER
|
2 | 322 |
| 9X-8256 |
WASHER
|
7 | 322 |
| 8T-4223 |
WASHER
|
2 | 322 |
