| Part No. | Name | Qty | Page |
|---|---|---|---|
| 196-1571 |
SUPPORT AS
|
1 | 721 |
| 171-7486 |
GUARD AS
|
1 | 721 |
| 196-1569 |
SUPPORT AS
|
1 | 721 |
| 8T-4139 |
BOLT (L=30mm)
|
6 | 721 |
| 8T-4223 |
WASHER
|
8 | 721 |
| 7X-2553 |
BOLT (L=40mm)
|
2 | 721 |
| 124-8758 |
PLATE (WARNING)
|
1 | 721 |
| 201-4534 |
PIN
|
2 | 721 |
| 176-1928 |
BRACKET AS
|
2 | 721 |
| 5D-4822 |
RING
|
4 | 721 |
| 176-1925 |
SPRING AS
|
2 | 721 |
| 196-1572 |
LATCH AS
|
2 | 721 |
| 258-0330 |
BRACKET AS
|
2 | 721 |
| 6C-8382 |
SPRING
|
2 | 721 |
| 4I-6602 |
BOSS
|
8 | 721 |
| 096-4882 |
NUT
|
2 | 721 |
| 8T-4192 |
BOLT (L=25mm)
|
2 | 721 |
| 201-4535 |
PIN
|
2 | 721 |
| 9X-8257 |
WASHER
|
4 | 721 |
| 4B-4158 |
SCREW
|
4 | 721 |
| 7Y-0623 |
NUT
|
2 | 721 |
| 8T-4224 |
WASHER
|
4 | 721 |
| 196-1571 |
SUPPORT AS
|
1 | 712 |
| 171-7486 |
GUARD AS
|
1 | 712 |
| 196-1569 |
SUPPORT AS
|
1 | 712 |
| 8T-4139 |
BOLT (L=30mm)
|
6 | 712 |
| 8T-4223 |
WASHER
|
8 | 712 |
| 7X-2553 |
BOLT (L=40mm)
|
2 | 712 |
| 298-4254 |
FILM (FRONT GUARD)
|
1 | 712 |
| 201-4534 |
PIN
|
2 | 712 |
| 176-1928 |
BRACKET AS
|
2 | 712 |
| 5D-4822 |
RING
|
4 | 712 |
| 176-1925 |
SPRING AS
|
2 | 712 |
| 196-1572 |
LATCH AS
|
2 | 712 |
| 258-0330 |
BRACKET AS
|
2 | 712 |
| 6C-8382 |
SPRING
|
2 | 712 |
| 096-4882 |
NUT
|
2 | 712 |
| 8T-4192 |
BOLT (L=25mm)
|
2 | 712 |
| 201-4535 |
PIN
|
2 | 712 |
| 9X-8257 |
WASHER
|
4 | 712 |
| 219-0305 |
FILM (WARNING)
|
1 | 712 |
| 7Y-0623 |
NUT
|
2 | 712 |
| 8T-4224 |
WASHER
|
4 | 712 |
