| Part No. | Name | Qty | Page |
|---|---|---|---|
| 227-6194 |
227-6194
|
1 | 346 |
| 3E-2338 |
PLUG
|
2 | 347 |
| 7Y-0644 |
SPACER
|
1 | 347 |
| 7Y-0639 |
GEAR (Z=21)
|
1 | 347 |
| 8T-4167 |
WASHER
|
20 | 347 |
| 7Y-0642 |
GEAR (Z=63)
|
1 | 347 |
| 8T-4240 |
RING
|
3 | 347 |
| 7Y-0643 |
CARRIER
|
1 | 347 |
| 9X-6032 |
BOLT (L=30mm)
|
12 | 347 |
| 7Y-0645 |
CARRIER
|
1 | 347 |
| 7Y-0659 |
GEAR (Z=22)
|
3 | 347 |
| 7Y-0661 |
SHAFT
|
3 | 347 |
| 7Y-0662 |
SHAFT
|
4 | 347 |
| 1U-8846 |
GASKET MAKER (6ml) THE FOLLOWING SERVICE REPAIR IS AVAILABLE:
|
1 | 347 |
| 7Y-0663 |
GEAR (Z=20)
|
4 | 347 |
| 7Y-0667 |
RING
|
1 | 347 |
| 7Y-0673 |
GEAR
|
1 | 347 |
| 7Y-0676 |
GEAR (Z=24)
|
3 | 347 |
| 7Y-0731 |
CARRIER AS
|
1 | 347 |
| 7Y-0732 |
CARRIER
|
1 | 347 |
| 7Y-0656 |
SHAFT
|
3 | 347 |
| 267-6809 |
SHIM (T=0.75mm)
|
1 | 347 |
| 7Y-1056 |
SHIM (T=0.8mm)
|
1 | 347 |
| 267-6810 |
SHIM (T=0.85mm)
|
1 | 347 |
| 267-6811 |
SHIM (T=0.9mm)
|
1 | 347 |
| 267-6812 |
SHIM (T=0.95mm)
|
1 | 347 |
| 7Y-1057 |
SHIM (T=1.0mm)
|
1 | 347 |
| 267-6813 |
SHIM (T=1.2mm)
|
1 | 347 |
| 267-6814 |
SHIM (T=1.4mm)
|
1 | 347 |
| 267-6815 |
SHIM (T=1.8mm)
|
1 | 347 |
| 267-6816 |
SHIM (T=2.0mm)
|
1 | 347 |
| 267-6817 |
SHIM (T=2.3mm)
|
1 | 347 |
| 7Y-1094 |
WASHER
|
14 | 347 |
| 7Y-5235 |
BOLT (L=190mm)
|
20 | 347 |
| 094-0577 |
PLATE (T=7.00mm)
|
1 | 347 |
| 094-0578 |
PLATE (T=8.00mm)
|
1 | 347 |
| 094-0579 |
PLATE (T=9.00mm)
|
1 | 347 |
| 094-0580 |
PLATE (T=10.00mm)
|
1 | 347 |
| 110-7231 |
GEAR (Z=18)
|
1 | 347 |
| 114-1541 |
PIN
|
6 | 347 |
| 191-2521 |
GEAR (Z=23)
|
1 | 347 |
| 199-4582 |
BEARING AS
|
3 | 347 |
| 199-4583 |
BEARING AS
|
11 | 347 |
| 213-4737 |
SEAL GP
|
1 | 347 |
| 227-6190 |
HOUSING
|
1 | 347 |
| 227-6191 |
HOUSING
|
1 | 347 |
| 227-6192 |
GEAR
|
1 | 347 |
| 279-0344 |
BEARING AS
|
2 | 347 |
| 093-1731 |
RING
|
1 | 347 |
| 094-0584 |
WASHER
|
6 | 347 |
