| Part No. | Name | Qty | Page |
|---|---|---|---|
| 087-4707 |
SPRING
|
4 | 789 |
| 131-5818 |
SPRING
|
4 | 789 |
| 099-6136 |
WASHER
|
8 | 789 |
| 095-0936 |
RING
|
4 | 789 |
| 126-1865 |
SPRING
|
4 | 789 |
| 126-1866 |
SPRING
|
4 | 789 |
| 147-4221 |
PISTON
|
4 | 789 |
| 6V-8400 |
SEAL - O - RING (ID=30.01mm)
|
4 | 789 |
| 165-9554 |
PLUG
|
4 | 789 |
| 119-5389 |
PACKING
|
4 | 789 |
| 165-9552 |
PUSHROD
|
4 | 789 |
| 087-4710 |
SETSCREW
|
4 | 789 |
| 8T-4133 |
NUT
|
4 | 789 |
| 087-5709 |
BELLOW
|
2 | 789 |
| 087-5708 |
PEDAL
|
2 | 789 |
| 8T-0343 |
BOLT (L=55mm)
|
2 | 789 |
| 119-5388 |
CAP
|
4 | 789 |
| 165-9463 |
COVER
|
2 | 789 |
| 119-5391 |
SEAT
|
4 | 789 |
| 119-5392 |
BUSHING
|
4 | 789 |
| 153-5223 |
BALL
|
12 | 789 |
| 165-9551 |
SEAT
|
4 | 789 |
| 099-6137 |
WASHER
|
4 | 789 |
| 099-6141 |
WASHER
|
4 | 789 |
| 8T-1158 |
BOLT (L=20mm)
|
2 | 789 |
| 099-6145 |
CAMSHAFT
|
2 | 789 |
| 099-6144 |
BUSHING
|
4 | 789 |
| 095-1260 |
SETSCREW
|
2 | 789 |
| 8T-6759 |
PLUG
|
6 | 789 |
| 9M-5590 |
BALL
|
2 | 789 |
| 107-6479 |
PLUG
|
2 | 789 |
| 095-1578 |
SEAL - O - RING (ID=9.80mm)
|
2 | 789 |
| 165-9464 |
SEAT
|
2 | 789 |
| 165-9553 |
COVER
|
1 | 789 |
