| Part No. | Name | Qty | Page |
|---|---|---|---|
| 165-9470 |
165-9470
|
1 | 612 |
| 199-0403 |
SHEET AS
|
1 | 613 |
| 199-0405 |
LINER
|
1 | 613 |
| 104-8774 |
HOSE AS (NOM 06, L=2200mm)
|
2 | 613 |
| 104-8783 |
HOSE AS (NOM 06, L=2150mm)
|
2 | 613 |
| 108-7203 |
HOSE AS (NOM 06, L=2600mm)
|
1 | 613 |
| 134-6918 |
HOSE AS (NOM 06, L=2150mm)
|
2 | 613 |
| 6V-9001 |
ELBOW
|
6 | 613 |
| 6V-8724 |
ELBOW
|
9 | 613 |
| 6V-8781 |
TEE
|
6 | 613 |
| 8T-1905 |
ELBOW
|
3 | 613 |
| 165-9470 |
VALVE GP
|
1 | 613 |
| 176-4684 |
SUPPORT
|
1 | 613 |
| 4I-0995 |
HOSE AS (NOM 06, L=2000mm)
|
1 | 613 |
| 4I-3988 |
HOSE AS (NOM 06, L=2250mm)
|
4 | 613 |
| 4I-3991 |
HOSE AS (NOM 06, L=2100mm)
|
1 | 613 |
| 4I-8799 |
HOSE AS (NOM 06, L=2900mm)
|
1 | 613 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 613 |
| 4I-9522 |
BAND (L2,YELLOW)
|
4 | 613 |
| 4I-9523 |
BAND (L3,BLUE)
|
4 | 613 |
| 4I-9524 |
BAND (L4,BROWN)
|
4 | 613 |
| 4I-9525 |
BAND (R1,ORANGE)
|
4 | 613 |
| 4I-9526 |
BAND (R2,WHITE)
|
4 | 613 |
| 4I-9527 |
BAND (R3,GREEN)
|
4 | 613 |
| 4I-9528 |
BAND (R4,PURPLE)
|
4 | 613 |
| 7Y-4390 |
HOSE AS (NOM 06, L=2400mm)
|
1 | 613 |
| 7Y-8478 |
HOSE AS (NOM 06, L=2100mm)
|
1 | 613 |
| 8T-4121 |
WASHER
|
8 | 613 |
| 8T-4136 |
BOLT (L=25mm)
|
4 | 613 |
| 8T-4189 |
BOLT (L=20mm)
|
2 | 613 |
| 8T-4191 |
BOLT (L=16mm)
|
4 | 613 |
| 8T-4224 |
WASHER
|
2 | 613 |
| 7K-1181 |
STRAP
|
9 | 613 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
24 | 613 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
30 | 613 |
| 204-8191 |
SUPPORT
|
1 | 613 |
