| Part No. | Name | Qty | Page |
|---|---|---|---|
| 165-9470 |
165-9470
|
1 | 513 |
| 4I-0995 |
HOSE AS (NOM 06, L=2000mm)
|
1 | 514 |
| 4I-3981 |
HOSE AS (NOM 06, L=2750mm)
|
1 | 514 |
| 4I-6003 |
HOSE AS (NOM 06, L=2650mm)
|
1 | 514 |
| 4I-8799 |
HOSE AS (NOM 06, L=2900mm)
|
1 | 514 |
| 4I-9521 |
BAND (L1,RED)
|
4 | 514 |
| 4I-9522 |
BAND (L2,YELLOW)
|
4 | 514 |
| 4I-9523 |
BAND (L3,BLUE)
|
4 | 514 |
| 4I-9524 |
BAND (L4,BROWN)
|
4 | 514 |
| 4I-9525 |
BAND (R1,ORANGE)
|
4 | 514 |
| 4I-9526 |
BAND (R2,WHITE)
|
4 | 514 |
| 4I-9527 |
BAND (R3,GREEN)
|
4 | 514 |
| 4I-9528 |
BAND (R4,PURPLE)
|
4 | 514 |
| 7K-1181 |
STRAP
|
11 | 514 |
| 7Y-4173 |
HOSE AS (NOM 06, L=2800mm)
|
1 | 514 |
| 087-5303 |
HOSE AS (NOM 06, L=2300mm)
|
1 | 514 |
| 104-8768 |
HOSE AS (NOM 06, L=2700mm)
|
1 | 514 |
| 104-8783 |
HOSE AS (NOM 06, L=2150mm)
|
1 | 514 |
| 108-7203 |
HOSE AS (NOM 06, L=2600mm)
|
5 | 514 |
| 124-1008 |
GUARD
|
1 | 514 |
| 134-6918 |
HOSE AS (NOM 06, L=2150mm)
|
1 | 514 |
| 165-9470 |
VALVE GP
|
1 | 514 |
| 176-4366 |
SUPPORT
|
1 | 514 |
| 179-7616 |
HOSE AS (NOM 06, L=2500mm)
|
1 | 514 |
| 218-1336 |
HOSE AS (NOM 06, L=2230mm)
|
1 | 514 |
| 255-1671 |
GROMMET
|
1 | 514 |
| 115-8645 |
GUARD
|
2 | 514 |
| 6V-9001 |
ELBOW
|
6 | 514 |
| 6V-8724 |
ELBOW
|
8 | 514 |
| 8T-1905 |
ELBOW
|
2 | 514 |
| 176-4684 |
SUPPORT
|
1 | 514 |
| 8T-4121 |
WASHER
|
4 | 514 |
| 8T-4191 |
BOLT (L=16mm)
|
4 | 514 |
| 8T-4192 |
BOLT (L=25mm)
|
4 | 514 |
| 8T-4223 |
WASHER
|
4 | 514 |
| 8T-4224 |
WASHER
|
2 | 514 |
| 8T-4908 |
BOLT (L=25mm)
|
2 | 514 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
16 | 514 |
| 6V-8397 |
SEAL - O - RING (OD=12.83mm)
|
16 | 514 |
