| Part No. | Name | Qty | Page |
|---|---|---|---|
| 240-3066 |
240-3066
|
1 | 760 |
| 240-3066 |
VALVE GP
|
1 | 761 |
| 158-8159 |
HOUSING
|
5 | 761 |
| 6E-2274 |
COVER
|
5 | 761 |
| 111-9959 |
PLUG
|
1 | 761 |
| 8T-4121 |
WASHER
|
20 | 761 |
| 8T-4195 |
BOLT (L=30mm)
|
28 | 761 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
4 | 761 |
| 6E-4816 |
PLUG GP
|
2 | 761 |
| 6E-5731 |
VALVE
|
1 | 761 |
| 236-6419 |
PLUG
|
1 | 761 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
1 | 761 |
| 7I-1248 |
SPRING
|
1 | 761 |
| 7Y-8099 |
COVER
|
2 | 761 |
| 4J-0520 |
SEAL - O - RING (ID=32.92mm)
|
2 | 761 |
| 153-5291 |
CONNECTOR
|
1 | 761 |
| 236-6421 |
PLUG
|
1 | 761 |
| 6V-3922 |
SEAL - O - RING (ID=18.72mm)
|
1 | 761 |
| 153-5293 |
SPRING
|
1 | 761 |
| 153-5292 |
VALVE
|
1 | 761 |
| 153-5290 |
PLUG
|
1 | 761 |
| 7M-8485 |
SEAL - O - RING (ID=29.74mm)
|
1 | 761 |
| 153-5288 |
SPRING
|
1 | 761 |
| 153-5289 |
GUIDE
|
1 | 761 |
| 2M-9780 |
SEAL - O - RING (ID=19.18mm)
|
1 | 761 |
| 095-1787 |
RING
|
1 | 761 |
| 4I-6397 |
RING
|
1 | 761 |
| 109-5152 |
109-5152
|
1 | 762 |
| 6V-5597 |
SEAL - O - RING (ID=40.94mm)
|
6 | 763 |
| 6E-5731 |
VALVE
|
3 | 763 |
| 236-6419 |
PLUG
|
4 | 763 |
| 095-1590 |
SEAL - O - RING (ID=21.80mm)
|
4 | 763 |
| 7I-1248 |
SPRING
|
4 | 763 |
| 250-2508 |
VALVE GP
|
3 | 763 |
| 153-5286 |
VALVE
|
1 | 763 |
| 109-5152 |
VALVE GP
|
1 | 763 |
| 095-1787 |
RING
|
4 | 763 |
