| Part No. | Name | Qty | Page |
|---|---|---|---|
| 169-5586 |
HOUSING
|
1 | 359 |
| 207-1571 |
SEAL GP
|
1 | 359 |
| 168-8452 |
BEARING
|
2 | 359 |
| 7Y-0595 |
SPACER
|
3 | 359 |
| 169-5596 |
STOPPER
|
1 | 359 |
| 171-9298 |
SEAL - O - RING (ID=351.00mm)
|
1 | 359 |
| 191-2676 |
GEAR (Z=72)
|
1 | 359 |
| 169-5599 |
CARRIER
|
1 | 359 |
| 169-5590 |
GEAR (Z=24)
|
1 | 359 |
| 191-2571 |
CARRIER
|
1 | 359 |
| 171-9387 |
GEAR (Z=64)
|
1 | 359 |
| 7M-8485 |
SEAL - O - RING (ID=29.74mm)
|
2 | 359 |
| 3E-2338 |
PLUG
|
2 | 359 |
| 191-2686 |
CARRIER AS
|
1 | 359 |
| 191-2679 |
SHAFT
|
3 | 359 |
| 191-2687 |
RACE
|
3 | 359 |
| 093-1731 |
RING
|
2 | 359 |
| 169-5589 |
GEAR (Z=24)
|
1 | 359 |
| 094-0578 |
PLATE (T=8.00mm)
|
1 | 359 |
| 094-0579 |
PLATE (T=9.00mm)
|
1 | 359 |
| 094-0580 |
PLATE (T=10.00mm)
|
1 | 359 |
| 169-5585 |
HOUSING
|
1 | 359 |
| 096-3216 |
SETSCREW
|
2 | 359 |
| 191-2683 |
GEAR (Z=20)
|
1 | 359 |
| 191-2684 |
GEAR (Z=21)
|
3 | 359 |
| 096-0433 |
RING
|
3 | 359 |
| 191-2689 |
WASHER
|
3 | 359 |
| 191-2685 |
BEARING AS
|
3 | 359 |
| 9X-6032 |
BOLT (L=30mm)
|
12 | 359 |
| 179-8733 |
BOLT (L=170mm)
|
16 | 359 |
| 8T-4123 |
WASHER
|
16 | 359 |
| 199-4503 |
COVER
|
1 | 359 |
| 191-2690 |
WASHER
|
3 | 359 |
| 1U-8846 |
GASKET MAKER (4ml)
|
1 | 359 |
| 191-2569 |
BEARING AS
|
3 | 359 |
| 169-5601 |
SHAFT
|
3 | 359 |
| 169-5592 |
GEAR (Z=23)
|
3 | 359 |
| 094-1528 |
WASHER
|
12 | 359 |
| 095-0891 |
PIN
|
6 | 359 |
| 169-5593 |
GEAR (Z=23)
|
3 | 359 |
| 191-2570 |
BEARING AS
|
6 | 359 |
| 169-5602 |
SHAFT
|
3 | 359 |
