| Part No. | Name | Qty | Page |
|---|---|---|---|
| 129-6466 |
129-6466
|
1 | 896 |
| 4I-5021 |
BLADE AS
|
1 | 897 |
| 167-7074 |
BRACKET AS
|
1 | 897 |
| 167-7079 |
MOTOR AS
|
1 | 897 |
| 6V-7357 |
BOLT (L=25mm)
|
3 | 897 |
| 9X-8256 |
WASHER
|
3 | 897 |
| 8T-4134 |
NUT
|
3 | 897 |
| 167-7062 |
BUMPER AS
|
1 | 897 |
| 8T-4136 |
BOLT (L=25mm)
|
4 | 897 |
| 8T-4121 |
WASHER
|
8 | 897 |
| 4I-5020 |
ARM AS
|
1 | 897 |
| 8T-4191 |
BOLT (L=16mm)
|
4 | 897 |
| 4I-1163 |
BRACKET
|
1 | 897 |
| 5C-9553 |
BOLT (L=16mm)
|
2 | 897 |
| 156-6647 |
GLASS AS
|
1 | 897 |
| 9X-2042 |
SCREW
|
2 | 897 |
| 124-3966 |
STOPPER
|
1 | 897 |
| 144-9691 |
PACKING
|
2 | 897 |
| 144-9692 |
RETAINER
|
2 | 897 |
| 151-6705 |
PACKING
|
1 | 897 |
| 129-6466 |
SWITCH AS
|
1 | 897 |
| 156-6646 |
BRACKET
|
1 | 897 |
| 9X-2044 |
SCREW
|
2 | 897 |
| 8H-3481 |
LOCKWASHER
|
2 | 897 |
| 9X-8256 |
WASHER
|
2 | 897 |
