| Part No. | Name | Qty | Page |
|---|---|---|---|
| 3E-7859 |
SOLENOID AS
|
1 | 317 |
| 5S-7349 |
BOLT (L=13mm)
|
4 | 317 |
| 6V-8188 |
NUT
|
4 | 317 |
| 4M-1828 |
RETAINER
|
1 | 317 |
| 036-9821 |
WASHER
|
1 | 317 |
| 7T-3269 |
BOOT
|
1 | 317 |
| 7T-3270 |
PLUNGER AS
|
1 | 317 |
| 9M-7609 |
SPRING
|
1 | 317 |
| 4M-1827 |
RETAINER
|
1 | 317 |
| 102-9863 |
TERMINAL AS
|
1 | 317 |
| 4M-1831 |
PLUG
|
1 | 317 |
| 7L-2894 |
GASKET
|
1 | 317 |
| 9X-4824 |
COVER INSULATOR BUSHING THE FOLLOWING REPAIR KITS ARE AVAILABLE:
|
1 | 317 |
| 7X-1952 |
HOUSING AS
|
1 | 317 |
| 3E-7858 |
HOUSING AS
|
1 | 317 |
| 3E-7860 |
KIT (BUSHING) (INCLUDES PARTS MARKED J)
|
1 | 317 |
| 3E-7857 |
DRIVE AS
|
1 | 317 |
| 036-9823 |
BOLT
|
5 | 317 |
| 9X-4825 |
BRUSH KIT (INCLUDES PARTS MARKED L)
|
1 | 317 |
| 7X-3373 |
BOLT (L=22mm)
|
6 | 317 |
| 3F-0379 |
SCREW
|
8 | 317 |
| 3E-7861 |
KIT (LEVER) (INCLUDES PARTS MARKED P)
|
1 | 317 |
| 3E-7855 |
ARMATURE AS
|
1 | 317 |
| 7X-1950 |
SHOE
|
4 | 317 |
| 3E-7852 |
COIL AS
|
1 | 317 |
| 106-7149 |
HOUSING AS
|
1 | 317 |
| 9X-4821 |
PLATE AS SPACER RING
|
1 | 317 |
| 8T-4205 |
WASHER
|
4 | 317 |
| 8T-0328 |
WASHER
|
2 | 317 |
| 4B-2049 |
NUT
|
2 | 317 |
| 8F-1434 |
LOCKWASHER
|
1 | 317 |
| 2H-3429 |
RING SCREW RETAINER LEVER AS
|
1 | 317 |
| 3E-7853 |
TERMINAL SHAFT AS RING WASHER
|
1 | 317 |
| 7X-0562 |
WASHER
|
4 | 317 |
| 7T-3454 |
INSULATOR
|
1 | 317 |
| 7T-3451 |
INSULATOR
|
1 | 317 |
| 8T-8569 |
INSULATOR
|
1 | 317 |
| 9X-4271 |
CONNECTOR SEAL - O - RING SCREW SCREW AS BRUSH SPRING BUSHING BUSHING PLUG CUP WASHER NUT ILLUSTRATION
|
1 | 317 |
| 8T-9884 |
INSULATOR KIT (INCLUDES PARTS MARKED N) H 7 4 8 1 7 E 00
|
1 | 317 |
