CAT 320D 5P-0767 Parts Manual Diagram - HOSE (90cm)

Home › Parts Manual › CAT 320D › 5P-0767

Part No.

5P-0767

Name (EN)

HOSE (90cm)

Name (CN)

Qty

1 per assembly

Group

227-6166

System

FRAME AND BODY

Source

CAT Official Parts Manual

※ Click image to zoom · Page 259 of official CAT 320D parts manual

Part No.	Name	Qty	Page
2Y-5503	CORK	2	259
5D-1026	CLAMP	1	259
096-4755	PIN	1	259
7X-2563	BOLT (L=60mm)	32	259
7X-2576	BOLT (L=70mm)	12	259
8T-4123	WASHER	32	259
8T-4167	WASHER	12	259
1U-8846	GASKET MAKER (15ml)	1	259
2Y-5503	CORK	2	299
5D-1026	CLAMP	1	299
096-4755	PIN	1	299
7X-2563	BOLT (L=60mm)	32	299
7X-2576	BOLT (L=70mm)	12	299
8T-4123	WASHER	32	299
8T-4167	WASHER	12	299
1U-8846	GASKET MAKER (15ml)	1	299
