| Part No. | Name | Qty | Page |
|---|---|---|---|
| 257-2926 |
257-2926
|
1 | 860 |
| 3B-8489 |
FITTING
|
5 | 861 |
| 087-5805 |
PIN
|
2 | 861 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 861 |
| 168-2629 |
RING
|
2 | 861 |
| 210-2956 |
PIN
|
1 | 861 |
| 210-2957 |
PIN
|
1 | 861 |
| 254-3052 |
PIN
|
1 | 861 |
| 254-3053 |
PIN
|
1 | 861 |
| 257-2931 |
LATCH KIT
|
1 | 861 |
| 8T-4132 |
NUT
|
4 | 861 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 861 |
| 166-1494 |
SEAL
|
8 | 861 |
| 168-2628 |
PIN
|
2 | 861 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 861 |
| 308-8936 |
LINK AS
|
1 | 861 |
| 244-4360 |
BEARING
|
2 | 861 |
| 240-2912 |
BEARING
|
2 | 861 |
| 257-2926 |
257-2926
|
1 | 876 |
| 3B-8489 |
FITTING
|
5 | 877 |
| 087-5805 |
PIN
|
2 | 877 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 877 |
| 168-2629 |
RING
|
2 | 877 |
| 210-2956 |
PIN
|
1 | 877 |
| 210-2957 |
PIN
|
1 | 877 |
| 254-3052 |
PIN
|
1 | 877 |
| 254-3053 |
PIN
|
1 | 877 |
| 257-2930 |
HOOK GP
|
1 | 877 |
| 257-2931 |
LATCH KIT
|
1 | 877 |
| 8T-4132 |
NUT
|
4 | 877 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 877 |
| 166-1494 |
SEAL
|
8 | 877 |
| 168-2628 |
PIN
|
2 | 877 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 877 |
| 269-1626 |
LINK AS
|
1 | 877 |
| 244-4360 |
BEARING
|
2 | 877 |
| 240-2912 |
BEARING
|
2 | 877 |
