| Part No. | Name | Qty | Page |
|---|---|---|---|
| 272-6955 |
272-6955
|
1 | 378 |
| 099-3669 |
SHIM (T=1.00mm)
|
2 | 379 |
| 200-3255 |
NUT
|
1 | 379 |
| 099-6109 |
SHIM (T=1.05mm)
|
2 | 379 |
| 8T-4133 |
NUT
|
1 | 379 |
| 099-6110 |
SHIM (T=1.10mm)
|
2 | 379 |
| 191-5707 |
SPOOL AS
|
1 | 379 |
| 099-6111 |
SHIM (T=1.15mm)
|
2 | 379 |
| 190-7674 |
SEAL - O - RING (ID=23.70mm)
|
1 | 379 |
| 099-6112 |
SHIM (T=1.20mm)
|
2 | 379 |
| 190-7673 |
SEAL - O - RING (ID=37.70mm)
|
1 | 379 |
| 099-6113 |
SHIM (T=1.25mm)
|
2 | 379 |
| 173-3398 |
COVER
|
1 | 379 |
| 099-6115 |
SHIM (T=1.30mm)
|
2 | 379 |
| 185-0201 |
PIN AS
|
1 | 379 |
| 099-6117 |
SHIM (T=1.35mm)
|
2 | 379 |
| 129-7978 |
DOWEL
|
1 | 379 |
| 099-6118 |
SHIM (T=1.40mm)
|
2 | 379 |
| 185-0169 |
GUIDE
|
1 | 379 |
| 099-3670 |
SHIM (T=1.95mm)
|
2 | 379 |
| 099-6119 |
SHIM (T=1.45mm)
|
2 | 379 |
| 099-6120 |
SHIM (T=1.50mm)
|
2 | 379 |
| 099-6121 |
SHIM (T=1.55mm)
|
2 | 379 |
| 099-6122 |
SHIM (T=1.60mm)
|
2 | 379 |
| 099-6123 |
SHIM (T=1.65mm)
|
2 | 379 |
| 099-6124 |
SHIM (T=1.70mm)
|
2 | 379 |
| 099-6125 |
SHIM (T=1.75mm)
|
2 | 379 |
| 099-6126 |
SHIM (T=1.80mm)
|
2 | 379 |
| 099-6127 |
SHIM (T=1.85mm)
|
2 | 379 |
| 099-6128 |
SHIM (T=1.90mm)
|
2 | 379 |
| 150-5797 |
PIN
|
1 | 379 |
| 8T-4223 |
WASHER
|
6 | 379 |
| 8T-4196 |
BOLT (L=35mm)
|
2 | 379 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 379 |
| 285-4470 |
SEAL - O - RING (ID=151.99mm)
|
1 | 379 |
| 173-3397 |
LEVER
|
1 | 379 |
| 153-8623 |
RING
|
1 | 379 |
| 301-8294 |
ADJUSTER
|
1 | 379 |
| 301-6874 |
RETAINER
|
1 | 379 |
| 189-9763 |
SEAL - O - RING (ID=9.80mm)
|
3 | 379 |
| 200-3244 |
SPRING
|
1 | 379 |
| 200-3245 |
SPRING
|
1 | 379 |
| 200-3246 |
SPRING
|
1 | 379 |
| 215-9961 |
STOPPER
|
1 | 379 |
| 215-9962 |
STOPPER
|
1 | 379 |
| 173-3384 |
PISTON
|
1 | 379 |
| 225-4607 |
SETSCREW
|
2 | 379 |
| 234-4452 |
COVER
|
1 | 379 |
| 234-4453 |
COVER
|
1 | 379 |
| 094-1875 |
DOWEL
|
1 | 379 |
