| Part No. | Name | Qty | Page |
|---|---|---|---|
| 096-9492 |
PLATE
|
3 | 107 |
| 125-2930 |
TAPPET
|
6 | 107 |
| 125-2922 |
HOUSING
|
1 | 107 |
| 096-9495 |
PIN
|
1 | 107 |
| 5I-7508 |
GASKET
|
1 | 107 |
| 125-2931 |
ROLLER
|
1 | 107 |
| 085-9659 |
STUD
|
3 | 107 |
| 125-2932 |
BUSHING
|
1 | 107 |
| 085-9199 |
PLUG
|
1 | 107 |
| 125-2933 |
GUIDE
|
1 | 107 |
| 125-2923 |
ADAPTER
|
1 | 107 |
| 085-9888 |
EYEBOLT
|
1 | 107 |
| 125-2924 |
ADAPTER
|
1 | 107 |
| 5I-5147 |
VALVE
|
1 | 107 |
| 085-9832 |
COVER
|
1 | 107 |
| 095-2040 |
WASHER
|
2 | 107 |
| 096-9486 |
SCREW
|
2 | 107 |
| 5I-5148 |
GASKET
|
2 | 107 |
| 099-2389 |
GASKET
|
2 | 107 |
| 190-5859 |
EYEBOLT
|
1 | 107 |
| 125-2925 |
PLUG
|
6 | 107 |
| 1R-9206 |
NUT
|
3 | 107 |
| 096-8294 |
SEAL - O - RING
|
1 | 107 |
| 217-5436 |
PLUNGER AS
|
6 | 107 |
| 217-5437 |
VALVE
|
6 | 107 |
| 125-2928 |
SPRING
|
6 | 107 |
| 096-8307 |
GASKET
|
6 | 107 |
| 217-5438 |
HOLDER
|
6 | 107 |
| 217-5439 |
STOPPER
|
6 | 107 |
| 239-6440 |
SEAL
|
6 | 107 |
| 096-7632 |
GASKET H 9 3 4 0 4 E 01
|
3 | 107 |
| 085-9241 |
SHIM (T=0.20mm)
|
1 | 108 |
| 085-9229 |
SHIM (T=1.20mm)
|
1 | 108 |
| 085-9242 |
SHIM (T=0.25mm)
|
1 | 108 |
| 085-9238 |
SHIM (T=1.25mm)
|
1 | 108 |
| 096-9408 |
SHIM (T=0.30mm)
|
1 | 108 |
| 085-9230 |
SHIM (T=1.30mm)
|
1 | 108 |
| 085-9243 |
SHIM (T=0.35mm)
|
1 | 108 |
| 085-9245 |
SHIM (T=1.35mm)
|
1 | 108 |
| 085-9223 |
SHIM (T=0.40mm)
|
1 | 108 |
| 085-6720 |
SHIM (T=1.40mm)
|
1 | 108 |
| 085-9244 |
SHIM (T=0.45mm)
|
1 | 108 |
| 085-9246 |
SHIM (T=1.45mm)
|
1 | 108 |
| 085-9224 |
SHIM (T=0.50mm)
|
1 | 108 |
| 085-9239 |
SHIM (T=1.50mm)
|
1 | 108 |
| 085-9231 |
SHIM (T=0.55mm)
|
1 | 108 |
| 085-9247 |
SHIM (T=1.55mm)
|
1 | 108 |
| 085-9225 |
SHIM (T=0.60mm)
|
1 | 108 |
| 085-9240 |
SHIM (T=1.60mm)
|
1 | 108 |
| 085-9232 |
SHIM (T=0.65mm)
|
1 | 108 |
