CAT 320D 265-3578 Parts Manual Diagram - DRIVE AS

Home › Parts Manual › CAT 320D › 265-3578

Part No.

265-3578

Name (EN)

DRIVE AS

Name (CN)

Qty

1 per assembly

Group

230-2979

System

COOLING SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 74 of official CAT 320D parts manual

Part No.	Name	Qty	Page
281-3588	DRIVE AS	1	56
102-8805	RECEPTACLE KIT	1	56
186-3735	PIN	6	56
245-9344	FAN AS	1	56
265-3557	PLATE AS	1	56
7X-0818	BOLT (L=45mm)	6	56
8T-4189	BOLT (L=20mm)	6	56
8T-4200	BOLT (L=16mm)	3	56
8T-4224	WASHER	15	56
102-8805	RECEPTACLE KIT	1	74
186-3735	PIN	6	74
245-9344	FAN AS	1	74
265-3557	PLATE AS	1	74
7X-0818	BOLT (L=45mm)	6	74
8T-4189	BOLT (L=20mm)	6	74
8T-4200	BOLT (L=16mm)	3	74
8T-4224	WASHER	15	74
281-3588	DRIVE AS	1	75
102-8805	RECEPTACLE KIT	1	75
186-3735	PIN	6	75
245-9344	FAN AS	1	75
265-3557	PLATE AS	1	75
7X-0818	BOLT (L=45mm)	6	75
8T-4189	BOLT (L=20mm)	6	75
8T-4200	BOLT (L=16mm)	3	75
8T-4224	WASHER	15	75
