CAT 320D 262-3148 Parts Manual Diagram - HOSE AS

Home › Parts Manual › CAT 320D › 262-3148

Part No.

262-3148

Name (EN)

HOSE AS

Name (CN)

Qty

1 per assembly

Group

242-6481

System

HYDRAULIC SYSTEM

Source

CAT Official Parts Manual

※ Click image to zoom · Page 463 of official CAT 320D parts manual

Part No.	Name	Qty	Page
7K-1181	STRAP	7	463
153-8798	PLATE	1	463
253-6417	BRACKET	2	463
6V-8995	UNION	2	463
6V-9169	NUT	2	463
8T-4184	BOLT (L=45mm)	2	463
8T-4223	WASHER	6	463
8T-4956	BOLT (L=35mm)	4	463
6V-8398	SEAL - O - RING (OD=16.03mm)	2	463
7K-1181	STRAP	7	513
153-8798	PLATE	1	513
253-6417	BRACKET	2	513
6V-8995	UNION	2	513
6V-9169	NUT	2	513
8T-4184	BOLT (L=45mm)	2	513
8T-4223	WASHER	6	513
8T-4956	BOLT (L=35mm)	4	513
6V-8398	SEAL - O - RING (OD=16.03mm)	2	513
