CAT 320D 245-7926 Parts Manual Diagram - SUPPORT AS

Home › Parts Manual › CAT 320D › 245-7926

Part No.

245-7926

Name (EN)

SUPPORT AS

Name (CN)

Qty

1 per assembly

Group

259-7348

System

OPERATOR STATION

Source

CAT Official Parts Manual

※ Click image to zoom · Page 727 of official CAT 320D parts manual

Part No.	Name	Qty	Page
245-7922	245-7922	1	726
259-7346	259-7346	1	726
128-2135	SCREW	4	727
185-8284	COVER	1	727
234-6579	NUT	2	727
234-6580	CAP	2	727
234-6602	COVER	1	727
234-6604	COVER	1	727
259-7346	ARMREST GP	1	727
234-6608	COVER	1	727
234-6609	COVER	1	727
234-6610	COVER	1	727
235-8914	NUT	4	727
235-8966	BASE	2	727
245-7790	SCREW	2	727
245-7948	SCREW	4	727
9X-2041	SCREW	3	727
245-7922	245-7922	1	772
259-7346	259-7346	1	772
128-2135	SCREW	4	773
185-8284	COVER	1	773
234-6579	NUT	2	773
234-6580	CAP	2	773
234-6602	COVER	1	773
234-6604	COVER	1	773
259-7346	ARMREST GP	1	773
234-6608	COVER	1	773
234-6609	COVER	1	773
234-6610	COVER	1	773
235-8914	NUT	4	773
235-8966	BASE	2	773
245-7790	SCREW	2	773
245-7948	SCREW	4	773
9X-2041	SCREW	3	773
