| Part No. | Name | Qty | Page |
|---|---|---|---|
| 3B-8489 |
FITTING
|
5 | 855 |
| 087-5805 |
PIN
|
2 | 855 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 855 |
| 168-2629 |
RING
|
2 | 855 |
| 241-7325 |
LINK AS
|
1 | 855 |
| 244-4360 |
BEARING
|
2 | 855 |
| 240-2912 |
BEARING
|
2 | 855 |
| 254-3052 |
PIN
|
1 | 855 |
| 254-3053 |
PIN
|
1 | 855 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 855 |
| 166-1494 |
SEAL
|
6 | 855 |
| 168-2628 |
PIN
|
2 | 855 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 855 |
| 8T-4132 |
NUT
|
4 | 855 |
| 244-4254 |
LINK AS
|
1 | 855 |
| 244-4255 |
LINK
|
1 | 855 |
| 3B-8489 |
FITTING
|
5 | 871 |
| 087-5805 |
PIN
|
2 | 871 |
| 166-1486 |
SHIM (T=2.00mm)
|
2 | 871 |
| 168-2629 |
RING
|
2 | 871 |
| 241-7325 |
LINK AS
|
1 | 871 |
| 244-4360 |
BEARING
|
2 | 871 |
| 240-2912 |
BEARING
|
2 | 871 |
| 254-3052 |
PIN
|
1 | 871 |
| 254-3053 |
PIN
|
1 | 871 |
| 093-1344 |
SEAL - O - RING (ID=140.00mm)
|
4 | 871 |
| 166-1494 |
SEAL
|
6 | 871 |
| 168-2628 |
PIN
|
2 | 871 |
| 186-5644 |
BOLT (L=150mm)
|
2 | 871 |
| 8T-4132 |
NUT
|
4 | 871 |
| 244-4254 |
LINK AS
|
1 | 871 |
| 244-4255 |
LINK
|
1 | 871 |
