CAT 320D 212-8486 Parts Manual Diagram - PISTON (OS=0.50mm)

Home › Parts Manual › CAT 320D › 212-8486

Part No.

212-8486

Name (EN)

PISTON (OS=0.50mm)

Name (CN)

Qty

6 per assembly

Group

212-8548

System

BASIC ENGINE

Source

CAT Official Parts Manual

※ Click image to zoom · Page 37 of official CAT 320D parts manual

Part No.	Name	Qty	Page
178-6543	RING SET (STANDARD)	6	37
178-6544	RING SET (OS=0.25mm)	6	37
178-6545	RING SET (OS=0.50mm)	6	37
212-8484	PISTON (STANDARD)	6	37
212-8485	PISTON (OS=0.25mm)	6	37
094-7134	PIN	6	37
5I-7667	RING	12	37
5I-7668	ROD AS	6	37
5I-7539	BUSHING	1	37
094-7154	BOLT (L=85mm)	2	37
094-7516	NUT	2	37
5I-7637	BEARING (AVAILABLE IN SET WITH PAIR)	12	37
5I-7794	BEARING (US=0.25mm)	12	37
5I-7795	BEARING (US=0.50mm)	12	37
5I-7796	BEARING (US=0.75mm)	12	37
