CAT 320D 189-2717 Parts Manual Diagram - HINGE AS

Home › Parts Manual › CAT 320D › 189-2717

Part No.

189-2717

Name (EN)

HINGE AS

Name (CN)

Qty

1 per assembly

Group

259-7350

System

OPERATOR STATION

Source

CAT Official Parts Manual

※ Click image to zoom · Page 678 of official CAT 320D parts manual

Part No.	Name	Qty	Page
189-2847	SEAL	1	678
259-7351	HATCH AS	1	678
099-3506	SPRING AS	2	678
8T-4200	BOLT (L=16mm)	4	678
8T-4224	WASHER	4	678
9X-2042	SCREW	2	678
259-7352	CATCH	1	678
189-2847	SEAL	1	731
259-7351	HATCH AS	1	731
099-3506	SPRING AS	2	731
8T-4200	BOLT (L=16mm)	4	731
8T-4224	WASHER	4	731
9X-2042	SCREW	2	731
259-7352	CATCH	1	731
