| Part No. | Name | Qty | Page |
|---|---|---|---|
| 279-7869 |
279-7869
|
1 | 372 |
| 256-0093 |
256-0093
|
1 | 372 |
| 256-0093 |
HEAD GP
|
1 | 373 |
| 8T-4175 |
BOLT (L=90mm)
|
2 | 373 |
| 177-2470 |
COVER
|
1 | 373 |
| 094-1882 |
PLUG
|
11 | 373 |
| 7X-2557 |
BOLT (L=140mm)
|
1 | 373 |
| 095-7419 |
SCREW
|
4 | 373 |
| 177-2471 |
COVER
|
1 | 373 |
| 8T-4139 |
BOLT (L=30mm)
|
10 | 373 |
| 8T-4176 |
BOLT (L=90mm)
|
2 | 373 |
| 256-0096 |
HEAD GP
|
1 | 373 |
| 8T-4140 |
BOLT (L=60mm)
|
4 | 373 |
| 189-9763 |
SEAL - O - RING (ID=9.80mm)
|
6 | 373 |
| 200-3333 |
BLOCK
|
1 | 373 |
| 129-7979 |
DOWEL
|
4 | 373 |
| 8T-4136 |
BOLT (L=25mm)
|
8 | 373 |
| 247-8782 |
BODY
|
1 | 373 |
| 150-5782 |
COVER
|
2 | 373 |
| 129-7863 |
COVER
|
1 | 373 |
| 129-7857 |
GASKET
|
1 | 373 |
| 179-9763 |
FLANGE
|
1 | 373 |
| 3K-0360 |
SEAL - O - RING (ID=16.36mm)
|
2 | 373 |
| 9S-4185 |
PLUG
|
2 | 373 |
| 279-7869 |
279-7869
|
1 | 374 |
| 095-0946 |
RING
|
2 | 375 |
| 129-7927 |
BEARING
|
2 | 375 |
| 192-0573 |
PIN
|
4 | 375 |
| 242-6804 |
BEARING
|
4 | 375 |
| 193-1736 |
SEAL - O - RING (ID=79.40mm)
|
4 | 375 |
| 173-3473 |
PLATE
|
2 | 375 |
| 191-5709 |
PISTON AS
|
2 | 375 |
| 173-3498 |
BARREL AS
|
1 | 375 |
| 273-8314 |
SEAL - O - RING (ID=285.60mm)
|
1 | 375 |
| 190-4896 |
PLUG
|
2 | 375 |
| 247-8920 |
ORIFICE
|
2 | 375 |
| 273-8315 |
SEAL - O - RING (ID=84.40mm)
|
2 | 375 |
| 8T-4136 |
BOLT (L=25mm)
|
10 | 375 |
| 200-3334 |
COVER
|
1 | 375 |
| 129-7859 |
BEARING SET
|
2 | 375 |
| 118-4057 |
SPRING
|
18 | 375 |
| 7Y-4215 |
SPACER
|
2 | 375 |
| 173-3427 |
GUIDE
|
2 | 375 |
| 242-6801 |
SWASHPLATE AS
|
2 | 375 |
| 094-1875 |
DOWEL
|
1 | 375 |
| 173-3428 |
BEARING
|
1 | 375 |
| 242-6803 |
PIN
|
2 | 375 |
| 129-7921 |
RING
|
2 | 375 |
| 129-7855 |
GASKET
|
1 | 375 |
| 225-4544 |
SHAFT
|
1 | 375 |
