CAT 320D 095-7930 Parts Manual Diagram - SCREW

Home › Parts Manual › CAT 320D › 095-7930

Part No.

095-7930

Name (EN)

SCREW

Name (CN)

Qty

2 per assembly

Group

291-7559

System

OPERATOR STATION

Source

CAT Official Parts Manual

※ Click image to zoom · Page 708 of official CAT 320D parts manual

Part No.	Name	Qty	Page
3S-2093	STRAP	1	708
7Y-3919	HORN AS	1	708
095-0826	LOCKWASHER	2	708
7Y-3920	HORN AS	1	708
095-0826	LOCKWASHER	2	708
291-7560	HARNESS AS	1	708
291-7561	BRACKET	1	708
132-5789	CLIP	1	708
8T-4121	WASHER	3	708
8T-4191	BOLT (L=16mm)	3	708
3S-2093	STRAP	1	752
7Y-3919	HORN AS	1	752
095-0826	LOCKWASHER	2	752
7Y-3920	HORN AS	1	752
095-0826	LOCKWASHER	2	752
291-7560	HARNESS AS	1	752
291-7561	BRACKET	1	752
132-5789	CLIP	1	752
8T-4121	WASHER	3	752
8T-4191	BOLT (L=16mm)	3	752
