CAT 320C 5Q-3215 Parts Manual Diagram - ROLLER AS

Home › Parts Manual › CAT 320C › 5Q-3215

Part No.

5Q-3215

Name (EN)

ROLLER AS

Name (CN)

Qty

1 per assembly

Group

163-4144

System

FRAME AND BODY

Source

CAT Official Parts Manual

※ Click image to zoom · Page 454 of official CAT 320C parts manual

Part No.	Name	Qty	Page
8E-5031	RING	2	454
7F-8268	SEAL - O - RING (ID=53.57mm)	2	454
5G-2247	STOPPER	1	454
8E-5599	BEARING	2	454
6Y-0473	PLUG	1	454
8E-5035	SHAFT	1	454
8E-5037	COLLAR	2	454
9W-2142	SEAL GP	2	454
3E-3217	DOWEL	1	454
8E-5031	RING	2	335
7F-8268	SEAL - O - RING (ID=53.57mm)	2	335
5G-2247	STOPPER	1	335
8E-5599	BEARING	2	335
6Y-0473	PLUG	1	335
8E-5035	SHAFT	1	335
8E-5037	COLLAR	2	335
9W-2142	SEAL GP	2	335
3E-3217	DOWEL	1	335
