| Part No. | Name | Qty | Page |
|---|---|---|---|
| 5I-4921 |
BOLT (L=21mm)
|
2 | 21 |
| 5I-7740 |
SPRING
|
12 | 21 |
| 5I-7720 |
PIPE
|
2 | 21 |
| 5I-7739 |
VALVE (EXHAUST)
|
6 | 21 |
| 5I-7622 |
RING
|
4 | 21 |
| 2W-6047 |
WASHER
|
4 | 21 |
| 178-6532 |
ROCKER AS
|
6 | 21 |
| 5I-7590 |
ROCKER AS
|
6 | 21 |
| 5I-7631 |
BUSHING
|
1 | 21 |
| 5I-7631 |
BUSHING
|
1 | 21 |
| 094-9525 |
SCREW
|
1 | 21 |
| 094-9525 |
SCREW
|
1 | 21 |
| 091-3474 |
NUT
|
1 | 21 |
| 5I-7722 |
BRACKET
|
6 | 21 |
| 095-8638 |
WASHER
|
12 | 21 |
| 5I-7730 |
BOLT
|
6 | 21 |
| 8T-4189 |
BOLT (L=20mm)
|
6 | 21 |
| 5I-7721 |
SPRING
|
4 | 21 |
| 5I-7731 |
SHAFT AS
|
2 | 21 |
| 094-4696 |
PLUG
|
1 | 21 |
| 5I-7630 |
CAP
|
12 | 21 |
| 5I-7719 |
COTTER (AVAILABLE IN SET WITH PAIR)
|
24 | 21 |
| 5I-7625 |
RETAINER
|
12 | 21 |
| 5I-7624 |
SEAL
|
12 | 21 |
| 091-3474 |
NUT H 6 7 7 1 1 E 00
|
1 | 21 |
| 5I-4921 |
BOLT (L=21mm)
|
2 | 19 |
| 5I-7740 |
SPRING
|
12 | 19 |
| 5I-7720 |
PIPE
|
2 | 19 |
| 5I-7739 |
VALVE (EXHAUST)
|
6 | 19 |
| 5I-7622 |
RING
|
4 | 19 |
| 2W-6047 |
WASHER
|
4 | 19 |
| 178-6532 |
ROCKER AS
|
6 | 19 |
| 5I-7590 |
ROCKER AS
|
6 | 19 |
| 5I-7631 |
BUSHING
|
1 | 19 |
| 5I-7631 |
BUSHING
|
1 | 19 |
| 094-9525 |
SCREW
|
1 | 19 |
| 094-9525 |
SCREW
|
1 | 19 |
| 091-3474 |
NUT
|
1 | 19 |
| 5I-7722 |
BRACKET
|
6 | 19 |
| 095-8638 |
WASHER
|
12 | 19 |
| 5I-7730 |
BOLT
|
6 | 19 |
| 8T-4189 |
BOLT (L=20mm)
|
6 | 19 |
| 5I-7721 |
SPRING
|
4 | 19 |
| 5I-7731 |
SHAFT AS
|
2 | 19 |
| 094-4696 |
PLUG
|
1 | 19 |
| 5I-7630 |
CAP
|
12 | 19 |
| 5I-7719 |
COTTER (AVAILABLE IN SET WITH PAIR)
|
24 | 19 |
| 5I-7625 |
RETAINER
|
12 | 19 |
| 5I-7624 |
SEAL
|
12 | 19 |
| 091-3474 |
NUT H 6 7 7 1 1 E 00
|
1 | 19 |
