| Part No. | Name | Qty | Page |
|---|---|---|---|
| 244-8483 |
244-8483
|
1 | 495 |
| 179-9682 |
BODY AS
|
1 | 496 |
| 200-3244 |
SPRING
|
1 | 496 |
| 094-1882 |
PLUG
|
7 | 496 |
| 200-3245 |
SPRING
|
1 | 496 |
| 9S-4191 |
PLUG
|
1 | 496 |
| 095-1538 |
SEAL - O - RING (ID=38.70mm)
|
1 | 496 |
| 3J-1907 |
SEAL - O - RING (ID=11.89mm)
|
2 | 496 |
| 095-1527 |
SEAL - O - RING (ID=24.70mm)
|
1 | 496 |
| 6V-8200 |
BOLT (L=35mm)
|
6 | 496 |
| 200-3255 |
NUT
|
1 | 496 |
| 234-4453 |
COVER
|
1 | 496 |
| 173-3387 |
ADJUSTER
|
1 | 496 |
| 173-3413 |
COVER
|
1 | 496 |
| 225-0417 |
SETSCREW
|
1 | 496 |
| 8T-4196 |
BOLT (L=35mm)
|
2 | 496 |
| 200-3254 |
NUT
|
1 | 496 |
| 234-4452 |
COVER
|
1 | 496 |
| 185-0172 |
RETAINER
|
1 | 496 |
| 8T-4136 |
BOLT (L=25mm)
|
2 | 496 |
| 095-1519 |
SEAL - O - RING (ID=15.80mm)
|
1 | 496 |
| 173-3398 |
COVER
|
1 | 496 |
| 185-0169 |
GUIDE
|
1 | 496 |
| 225-4607 |
SETSCREW
|
2 | 496 |
| 094-1875 |
DOWEL
|
1 | 496 |
| 8T-4131 |
NUT
|
2 | 496 |
| 215-9962 |
STOPPER
|
1 | 496 |
| 095-1788 |
RING
|
1 | 496 |
| 190-7674 |
SEAL - O - RING (ID=23.70mm)
|
1 | 496 |
| 190-4896 |
PLUG
|
1 | 496 |
| 173-3384 |
PISTON
|
1 | 496 |
| 190-7673 |
SEAL - O - RING (ID=37.70mm)
|
1 | 496 |
| 153-8623 |
RING
|
1 | 496 |
| 215-9961 |
STOPPER
|
1 | 496 |
| 8F-8733 |
SEAL - O - RING (ID=151.99mm)
|
1 | 496 |
| 185-0201 |
PIN AS
|
1 | 496 |
| 129-7978 |
DOWEL
|
1 | 496 |
| 094-1881 |
PLATE
|
1 | 496 |
| 150-5797 |
PIN
|
1 | 496 |
| 191-5707 |
SPOOL AS
|
1 | 496 |
| 173-3397 |
LEVER
|
1 | 496 |
| 095-1528 |
SEAL - O - RING (ID=25.70mm)
|
1 | 496 |
| 099-3669 |
SHIM (T=1.00mm)
|
2 | 496 |
| 099-6109 |
SHIM (T=1.05mm)
|
2 | 496 |
| 099-6110 |
SHIM (T=1.10mm)
|
2 | 496 |
| 099-6111 |
SHIM (T=1.15mm)
|
2 | 496 |
| 099-6112 |
SHIM (T=1.20mm)
|
2 | 496 |
| 099-6113 |
SHIM (T=1.25mm)
|
2 | 496 |
| 099-6115 |
SHIM (T=1.30mm)
|
2 | 496 |
| 099-6117 |
SHIM (T=1.35mm)
|
2 | 496 |
